Parameter
number
Description Setting range Number of
decimal
Fieldbus
ID
Default value Actual
setting
28 Service
28.01 ID Invalid ID, 30, 37, 45, 60, 72, 85, 105, 142, 170,
210, 250, 300, 370, 470, 570, 720, 840, 1050,
1250
0 171 Invalid ID
28.02 Line contactor close time 0 ... 65535 ms 0 175 245 ms
28.03 TOR relay delay time 0 ... 300 s 1
-
0 s
28.04 Start without start command On / Off 0
-
Off
28.05 Step down level 10 ... 100 % 0 9 80 %
28.06 Torque profile start Constant setpoint, Linear ramp,
Progressive curve, High inertia curve
0 10 Linear ramp
28.07 Torque finish 30 ... 500 % 0 17 100 %
28.08 Torque tune 0 ... 1000 % 0 11 100 %
28.09 Torque ctrl gain 0.01 ... 10.00 2 12 0.02
28.10 Torque PI intergration time 0.001 ... 10 s 3 13 0.004 s
28.11 Torque slip 0.1 ... 100 % 1 14 1.0 %
28.12 Torque diff 0.1 ... 100 % 1 15 2.0 %
28.13 Torque filter time 0.01 ... 100 s 2 16 0.02 s
28.14 Mains lock setting Automatic lock, 50 Hz manual lock
60 Hz manual lock
0
-
Automatic lock
28.15 Minimum trig time 0.0 ... 1.0 ms 3
-
0.208 ms
28.16 Accel adapt U start ramp On / Off 0
-
Off
28.17 U start ramp switch level 10 ... 100 % 0
-
22 %
28.18 T start ramp switch level 10 ... 100 % 0
-
30 %
28.19 Stop ramp switch level 10 ... 100 % 0
-
52 %
28.20 In-Line gain
0.0 ... 30.0 1
-
0.0
28.21 Inside delta gain 0.0 ... 30.0 1
-
3.0
28.22 Phase loss On / Off 0 33 On
28.23 Phase loss during TOR On / Off 0
-
On
28.24 Phase loss trip time 20 ... 4000 ms 0 34 500 ms
28.25 Phase loss trip angle 1 1 ... 240 0
-
12
28.26 Phase loss trip angle 2 1 ... 240 0 0 70
28.27 Bad network quality On / Off 0 35 On
28.28 Low supply voltage On / Off 0 37 On
28.29 High current fault On / Off 0 38 On
28.30 Shunt fault On / Off 0 40 On
28.31 Short circuit thyristor On / Off 0 39 On
28.32 Open circuit thyristor On / Off 0
-
On
28.33 Thyristor overload On / Off 0 41 On
28.34 Heat sink over temp On / Off 0
-
On
28.35 Faulty connection On / Off 0
-
On
28.36 Faulty usage On / Off 0
-
On
28.37 Close bypass curr lvl 0.5 ... 4.0 x I
e
1 28 1.2 x I
e
28.38 Simulation motor M3AA 100L 2 (Ie = 5.2 A), M3BP 112M 4
(Ie = 7.4 A), M2AA 180MLA 6G (Ie = 29.3 A),
M2AA 180MLB 4G (Ie = 39.9 A), M3AA 250SMA 8
(Ie = 62.3 A), M3AA 200MLB 2 (Ie = 59.2 A),
M2AA 225SMA 2G (Ie = 74.7 A), M2BP 250SMA
4G (Ie 96.6 A), M2BA 280SMB 2L (Ie = 144.9 A),
M2BA 315SMB 4L (Ie = 221.8 A), M2BA 315MLA
2L (Ie = 319.6A), M4BP 200MLB 2G (Ie = 59.3 A),
M3BP 315LKB 4K (Ie = 330.4 A), M3BP 315MLA
2M (Ie = 255.4 A),M3BP 280MLA 4M (Ie 151.5 A),
M3BP 355SMC 6K (Ie = 325.6 A),
0 29 M3AA
250SMA 8
(Ie = 62.3 A)
28.39 Simulation load No load, Linear Load, Progressive load,
High inertia load
0 30 Progressive
load
28.40 Simulation connection Auto, In line, Inside delta UI, Inside delta IU, Two
phase (L1 shorted), Two phase (L2 shorted), Two
phase (L2 shorted), Unknown
0
-
In line
28.41 System mode Normal, Demo, Small motor 0 31 Normal
28.42 Limp mode On / Off 0 25 Off
28.43 Motor connection Auto, In line, Inside delta UI, Inside delta IU, Two
phase (L1 shorted), Two phase (L2 shorted), Two
phase (L2 shorted), Unknown
0 27 Auto
7
