Parameter
number
Description Setting range Number of
decimal
Fieldbus
ID
Default value Actual
setting
12 Communication
12.13 Fieldbus DI 1 None, Start feedback, Stop feedback, Fault
reset feedback, Slow speed rev feedback,
Slow speed forw feedback, Start 1 feedback,
Start 2 feedback, Start 3 feedback, Motor
heating feedback, User defined feedback,
Stand still brake feedback, Emergency mode
feedback, Start reverse feedback, Run status,
TOR status, Line, Phase sequence, Event
group 0 status, Event group 1 status, Event
group 2 status, Event group 3 status, Event
group 4 status, Event group 5 status, Event
group 6 status, Sequence 1 Run status,
Sequence 2 Run status, Sequence 3 Run
status, Sequence 1 TOR status, Sequence
2 TOR status, Sequence 3 TOR status, Run
reverse status *** **
0 142 Line
12.13 Fieldbus DI 2 0 ... 32 *** ** 0 143 Phase
sequence
12.14 Fieldbus DI 3 0 ... 32 *** ** 0 144 Event group 0
status
12.15 Fieldbus DI 4 0 ... 32 *** ** 0 161 Event group 1
status
12.16 Fieldbus DI 5 0 ... 32 *** ** 0 162 Start
feedback
12.17 Fieldbus DI 6 0 ... 32 *** ** 0 163 Stop
feedback
12.18 Fieldbus DI 7 0 ... 32 *** ** 0 164 Event group 2
status
12.19 Fieldbus DI 8 0 ... 32 *** ** 0 165 Event group 3
status
12.20 Fieldbus DI 9 0 ... 32 *** ** 0 166 Event group 4
status
12.21 Fieldbus DI 10 0 ... 32 *** ** 0 167 Event group 5
status
12.22 Fieldbus AI 1 None, Phase L1 current, Phase L2 current,
Active power (HP), Active power, Apparent
power, Mains voltage, Power factor, Motor
voltage, Active energy (resettable), EOL time
to trip, Mains frequency, Max phase current,
Motor current, Motor run time (resettable),
Motor temperature, Motor temperature
percent, Number of starts (resettable),
Phase sequence, PT100 temperature, PTC
resistance, Reactive energy (resettable),
Reactive power, Remaining time to start,
Thyristor temperature, Thyristor temperature
percent, EOL time to cool, Top event code,
Motor current percent, Thyristor run time
(resettable), Motor connection *** ***
0 168 Phase L1
current
12.23 Fieldbus AI 2 0 ... 32 *** *** 0 169 Phase L2
current
12.24 Fieldbus AI 3 0 ... 32 *** *** 0 172 Phase L3
current
12.25 Fieldbus AI 4 0 ... 32 *** *** 0 174 Max phase
current
12.26 Fieldbus AI 5 0 ... 32 *** *** 0 177 Mains
frequency
12.27 Fieldbus AI 6 0 ... 32 *** *** 0 178 Motor voltage
12.28 Fieldbus AI 7 0 ... 32 *** *** 0 179 Motor
temperature
percent
12.29 Fieldbus AI 8 0 ... 32 *** *** 0 180 Number
of starts
(resettable)
12.30 Fieldbus AI 9 0 ... 32 *** *** 0 183 Motor
run time
(resettable)
12.31 Fieldbus AI 10 0 ... 32 *** *** 0 186 Top event
code
7
