ABB PSTX30 - Page 118

Parameter
number
Description Setting range Number of
decimal
Fieldbus
ID
Default value Actual
setting
11 External IO
11.01 1DI0 function None, Reset, Enable, Slow speed forward,
Slow speed reverse, Motor heating, Stand still
brake, Start reverse, User defined protection,
Emergency mode, Fieldbus disable control,
Start 1, Start 2, Start 3 ***
0 145 None
11.02 1DI1 function 0 ... 15 *** 0 146 None
11.03 1DI2 function 0 ... 15 *** 0 147 None
11.04 1DI3 function None, Reset, Enable, Slow speed forward,
Slow speed reverse, Motor heating, Stand still
brake, Start reverse, User defined protection,
Emergency mode, Fieldbus disable control,
Start 1, Start 2, Start 3 ***
0 148 None
11.05 1DI4 function 0 ... 15 *** 0 149 None
11.06 2DI5 function 0 ... 15 *** 0 150 None
11.07 2DI6 function 0 ... 15 *** 0 151 None
11.08 2DI7 function 0 ... 15 *** 0 152 None
11.09 1DO0 function None, Run, Top of ramp, Event group 0,
Event group 1, Event group 2, Event group 3,
Event group 4, Event group 5, Event group 6,
Sequence 1 Run, Sequence 2 Run,
Sequence 3 Run, Sequence 1 TOR, Sequence
2 TOR, Sequence 3 TOR ****
0 153 4-20 mA
11.10 1DO1 function 0 ... 15 *** * 0 154 None
11.11 2DO2 function 0 ... 15 *** * 0 155 None
11.12 2DO3 function 0 ... 15 *** * 0 156 None
11.13 1AO0 reference 0-10 mA, 0-20 mA, 4-20 mA, 0-10 V 0 157 4-20 mA
11.14 1AO0 type Motor current [A], Mains voltage [V], Active
power [kW], Active power [HP], Reactive power
[kVAr], Apparent power [kVA], Active energy
[kWh], Reactive energy [kVArh], COS [θ], Motor
temperature [%], Thyristor temperature [%],
Motor voltage [%]
Mains frequency [Hz], PT100 temperature
[centigrade],PTCresistance[Ω]
0 158 Motor current
[A]
11.15 1AO0 max value 0 ... 1000000 0 159 500
11.16 1AO0 min value 0 ... 1000000 0 160 0
12 Communication
12.01 Com3 function None, Test, Modbus RTU slave. Extension I/O 0 26 Test
12.02 FB interface connector FbPlug, Modbus RTU, Anybus, None 0 32 None
12.03 Fieldbus control On / Off 0 45 Off
12.04 Fieldbus address 0 ... 65535 0 51 0
12.05 Fieldbus IP address 000.000.000.000 0 58 0
12.06 Fieldbus IP gateway 000.000.000.000 0 59 0
12.07 Fieldbus IP netmask 255.255.255.000 0 83 4294967040u
12.08 Fieldbus IP DHCP client On / Off 0 92 Off
12.09 FB baud rate 1200, 2400, 4800, 9600, 19200, 38400,
57600, 76800, 115200, 125000, 250000,
500000, auto
0 185 19200
12.10 FB parity No parity, Odd parity, Even parity 0 136 Even parity
12.11 FB stop bits 1 Stop bit, 2 Stop bits 0 141 1 Stop bit
7
