ABB PSTX30 - Page 117

Parameter
number
Description Setting range Number of
decimal
Fieldbus
ID
Default value Actual
setting
08 Sequence start
08.37 Kick start time seq 2 0.20 ... 2.00 s 2 0 0.20 s
08.38 Torque limit lvl seq 2 20 ... 200 % 0 0 150 %
08.39 Torque tune seq 2 0 ... 1000 % 0 0 100 %
08.40 Torque ctrl gain seq 2 0.01 ... 10.00 2 0 0.02
08.60 Ie seq 3 9.0 ... 1250 A 1 0 9.0 A
08.61 Start mode seq 3 Voltage ramp, Torque ramp, Full voltage start 0 0 Voltage ramp
08.62 Start ramp time seq 3 1 ... 120 s 0 0 10 s
08.63 Start ramp init lvl seq 3 10 ... 99 % 0 0 30 %
08.64 Curr lim level seq 3 0.5 ... 7.5 x
I
e
1 0 7.0 x I
e
08.65 Kick start seq 3 On / Off 0 0 Off
08.66 Kick start level seq 3 50 ... 100 % 0 0 70 %
08.67 Kick start time seq 3 0.2 ... 2.00 s 2 0 0.2 s
08.68 Torque limit lvl seq 3 20 ... 200 % 0 0 150 %
08.69 Torque tune seq 3 0 ... 1000 % 0 - 100 %
08.70 Torque ctrl gain seq 3 0.01 ... 10.0 2 - 0.02
09 Automatic restart
09.01 Auto-reset delay time 0 ... 3600 s 0 - 0 s
09.02 Auto-restart On / Off 0 - Off
09.03 Auto-restart max attempts 1 ... 10 0 - 5
10 Internal IO
10.01 In0 function None, Reset, Enable, Slow speed forward,
Slow speed reverse, Motor heating, Stand still
brake, Start reverse, User defined protection,
Emergency mode, Fieldbus disable control,
Start 1, Start 2, Start 3. *
0 130 Reset
10.02 In1 function 0 ... 15 * 0 131 None
10.03 In2 function 0 ... 15 * 0 132 None
10.04 K4 function None, Run, Top of ramp, Event group 0, Event
group 1, Event group 2, Event group 3, Event
group 4, Event group 5, Event group 6,
Sequence 1 RUN, Sequence 2 RUN,
Sequence 3 RUN, Sequence 1 TOR, Sequence
2 TOR, Sequence 3 TOR,
Run reverse **
0 133 Run
10.05 K5 function 0 ... 17 ** 0 134 Top of ramp
10.06 K6 function None, Run, Top of ramp, Event group 0,
Event group 1, Event group 2, Event group 3,
Event group 4, Event group 5, Event group 6,
Sequence 1 Run, Sequence 2 Run,
Sequence 3 Run
0 135 Event group 0
10.07 AO reference 0-10 mA, 0-20 mA, 4-20 mA, 0-10 V 0 137 4-20 mA
10.08 AO type Motor current [A], Mains voltage [V], Active
power [kW], Active power [HP], Reactive power
[kVAr], Apparent power [kVA], Active energy
[kWh], Reactive energy [kVArh], COS [COS [Φ],
Motor temperature [%], Thyristor temperature
[%], Motor voltage [%]
Mains frequency [Hz], PT100 temperature
[centigrade],PTCresistance[Ω]
0 138 Motor current
[A]
10.09 AO max value 0.0 ... 1000000.0 0 139 500.0
10.10 AO min value 0.0 ... 1000000.0 0 140 0.0
10.11 Ext therm sensor - ID No sensor, PTC element, Three-wire PT100,
Two-wire PT100, Thermistor switch
0 - No sensor
7
