Introduction
This chapter contains detailed descriptions of all the
softstarter functions and the parameters for configuring
them.
Functions
The functions in this chapter is presented in the following
order:
7.1 Functions
Chapter Function
7.1 Voltage ramp
7.1.1 Voltage ramp start
7.1.2 Voltage ramp stop
7.2 Torque ramp
7.2.1 Torque ramp start
7.2.2 Torque ramp stop
7.3 Full voltage start
7.4 Direct stop
7.5 Stand still brake
7.6 Current limit
7.7 Kick start
7.8 Slow speed
7.9 Motor heating
7.10 Sequence start
7.11 Automatic restart
7.12 Inputs/outpus
7.12.1 Digital Inputs
7.12.2 Relay outputs
7.12.3 Analog outputs
7.12.4 Temperature sensor
7.13 Fieldbus
7.14 Eventgroups
7.14.1 Protections
7.14.2 Warnings
7.14.3 Faults
7.15 Special features
Setting parameters
Set the parameters via HMI
With the HMI Keypad, parameters can be set as individual
parameter settings, or as a selection of predefined
parameters for different applications.
The HMI complete list consist of parameter groups that
are displayed:
7.2 Parameter groups
01 Motor rated current Ie
02 Start and stop
03 Limit
04 Kick start
05 Slow speed
06 Motor heating
07 Motor braking
08 Sequence start
09 Automatic restart
10 Internal IO
11 External IO
12 Communication
13 ... 19 Protections groups 0-7
20 ... 24 Warnings groups 0-4
25 Internal faults
26 External faults
27 Presentation
28 Service
For navigation sheets, see chapter 6.4. Parameters.
Set the parameters via Fieldbus/PLC
When Fieldbus is used, parameters can be modified from
the PLC.
More details about parameter settings modified via
Fieldbus/ PLC are provided in a separate document
specification. TBD (to be determined)
