Fieldbus Inputs/Outputs
Functions set in the softstarter as Fieldbus digital inputs
(DI) are in fact the digital inputs to the PLC i.e. the data
flow from the softstarter through the network to the PLC.
Fieldbus digital outputs (DO) are not configurable. The
output (DO) describes data flow from the network to the
softstarter i.e. appears as an input, from the softstarter
point of view.
Fieldbus communication is configured with the
following parameters:
Parameter Description Setting range Default value
12.01 Com3 function Sets the function of the Com3
port.
None, Test, Modbus RTU slave,
Extension IO
Test
12.02 FB interface connector Sets the Fieldbus interface
selection.
FbPlug, Modbus RTU, Anybus,
None
None
12.03 Fieldbus control Enables control from fieldbus. Off, On Off
12.04 Fieldbus address Sets the Bus address. 0 ... 65535 0
12.05 Fieldbus ip address Fieldbus IP: Sets the IP-
address.
0.0.0.0 ... 255.255.255.255 0.0.0.0
12.06 Fieldbus ip gateway Fieldbus IP: Sets the default
gateway.
0.0.0.0 ... 255.255.255.255
0.0.0.0
12.07 Fieldbus ip netmask Fieldbus IP: Sets the netmask. 0.0.0.0 ... 255.255.255.255 255.255.255.0
12.08 Fieldbus ip dhcp client Fieldbus IP: Enables dhcp. Off, On Off
12.09 FB baud rate*
Sets the baud rate of internal
Modbus-RTU interface,
Anybus DeviceNet and Anybus
Modbus-RTU.
1200, 2400, 4800, 9600, 19200,
38400, 57600, 76800, 115200,
125000, 250000,500000, Auto
* There are restrictions
on which baudrates
that can be used for
different protocols. See
separate Table below.
12.10 FB parity Sets parity for Anybus Modbus-
RTU.
No parity, Odd parity, Even parity Even parity
12.11 FB stop bits Select stop bits for Anybus
Modbus-RTU.
1 Stop bit, 2 Stop bits 1 Stop bit
12.12 Fieldbus DI 1 Sets the DI 1 programmable
digital input signal.
Emergency mode feedback,
Event group 0 ... 6 status,
Fault reset feedback,
Line,
Motor heating feedback,
None,
Phase sequence,
Run reverse status,
Run status,
Sequnce 1 ... 3 Run status,
Sequence 1 ... 3 TOR status,
Slow speed rev feedback,
Slow speed forw feedback,
Stand still brake feedback,
Start 1 ... 3 feedback,
Start feedback,
Start reverse feedback,
Stop feedback,
TOR status,
User defined feedback
Line
12.13 Fieldbus DI 2 Sets the DI 2 programmable
digital input signal.
Phase sequence
12.14 Fieldbus DI 3 Sets the DI 3 programmable
digital input signal.
Event group 0 status
12.15 Fieldbus DI 4 Sets the DI 4 programmable
digital input signal.
Eventgroup 1 status
12.16 Fieldbus DI 5 Sets the DI 5 programmable
digital input signal.
Start feedback
12.17 Fieldbus DI 6 Sets the DI 6 programmable
digital input signal.
Stop feedback
12.18 Fieldbus DI 7 Sets the DI 7 programmable
digital input signal.
Eventgroup 2 status
12.19 Fieldbus DI 8 Sets the DI 8 programmable
digital input signal.
Eventgroup 3 status
12.20 Fieldbus DI 9 Sets the DI 9 programmable
digital input signal.
Eventgroup 4 status
12.21 Fieldbus DI 10 Sets the DI 9 programmable
digital input signal.
Eventgroup 5 status
