GUID-2194B0F4-FC2C-4D2A-A689-83BAFC095DA3 V2 EN
Figure 48: Clearing indications and LEDs
4.2.10 Selecting programmable LEDs view
The programmable LEDs view shows the status of the programmable LEDs. These
are the same LEDs that are located on the upper right side of the LHMI panel.
• Click Programmable LEDs on the menu bar.
1MRS758754 B Section 4
Using the HMI
REC615 and RER615 69
Operation Manual
