Parameter Values (Range) Unit Step Default Description
2=Without Check
3=Current check
Retrip time 0...60000 ms 10 120 Delay timer for ret-
rip
CB failure delay 0...60000 ms 10 240 Delay timer for
backup trip
Table 521: CCBRBRF Non group settings (Advanced)
Parameter Values (Range) Unit Step Default Description
CB fault delay 0...60000 ms 10 5000 Circuit breaker faul-
ty delay
Measurement
mode
2=DFT
3=Peak-to-Peak
3=Peak-to-Peak Phase current
measurement
mode of function
Trip pulse time 0...60000 ms 10 200 Pulse length of ret-
rip and backup trip
outputs
Start latching
mode
1=Rising edge
2=Level sensitive
1=Rising edge Start reset delayed
or immediately
5.2.8 Monitored data
5.2.8.1
Table 522: CCBRBRF Monitored data
Name Type Values (Range) Unit Description
CCBRBRF Enum
1=on
2=blocked
3=test
4=test/blocked
5=off
Status
5.2.9 Technical data
Table 523: CCBRBRF Technical data
Characteristic Value
Operation accuracy Depending on the frequency of the measured current: f
n
±2
Hz
±1.5 % of the set value or ±0.002 × I
n
Operate time accuracy ±1.0 % of the set value or ±20 ms
Reset time Typically 40 ms
Retardation time <20 ms
