ABB RELION REX615 - Double-Point Information; Measured Value, Short Floating Point

• SPS.stVal
• SPC.stVal
• DPC.stSeld
• ACD.general/phsA/phsB/phsC/neut
• ACT.general/phsA/phsB/phsC/neut
Table 2: Single-point information
Type ASDU
GI 1 M_SP_NA_1 Single point
Event 30 M_SP_TB_1 Single point with
CP56Time2a
3.2.2 Double-point information
Double-point information is derived from several IEC 61850 data attributes.
• DPS.stVal
• DPC.stVal
Table 3: Double-point information
Type ASDU
GI 3 M_DP_NA_1 Double point
Event 31 M_DP_TB_1 Double point with
CP56Time2a
3.2.3 Measured value, short floating point
The short floating-point type (float32) is derived from the IEC 61850 data
classes/ attributes defined for measurand values. The default scaling for the
IEC 60870-5-104 value is 1, making it identical to the corresponding IEC 61850
measurand value (CDC.attribute/attribute/ …).
• MV.instMag/mag.f
• CMV.cVal.mag.f/instCVal.mag.f
• DEL.phsAB.instCVal.mag.f/phsBC.instCVal.mag.f/phsCA.instCVal.mag.f
• DEL.phsAB.cVal.mag.f/phsBC.cVal.mag.f/phsCA.cVal.mag.f
• WYE.phsA.instCVal.mag.f/phsB.instCVal.mag.f/phsC.instCVal.mag.f
• WYE.neut.instCVal.mag.f/res.instCVal.mag.f/net.instCVal.mag.f
• WYE.phsA.cVal.mag.f/phsB.cVal.mag.f/phsC.cVal.mag.f
• WYE.neut.cVal.mag.f/res.cVal.mag.f/net.cVal.mag.f
• SEQ.c1.instCVal.mag.f/c2.instCVal.mag.f/c3.instCVal.mag.f
Vendor-specific implementation
