ABB RELION REX615 - Measured Value, Scaled Integer; Integrated Totals

Table 4: Measured value, short floating point
Type ASDU
GI 13 M_ME_NC_1 Measurand, float32
Event 36 M_ME_TF_1 Measurand, float32
with CP56Time2a
3.2.4 Measured value, scaled integer
A scaled integer (int16) is derived from the IEC 61850 data classes/attributes
defined for integer values, that is, the common data classes dealing with either
integer or enumeral values. The default scaling for the IEC 60870-5-104 value is 1,
making it identical to the corresponding IEC 61850 value (CDC.attribute/attribute/
…).
• INS.stVal
• INC.stVal
• ENS.stVal
• ENC.stVal
Table 5: Measured value, scaled integer
Type ASDU
GI 11 M_ME_NB_1 Measurand, scaled in-
teger
Event 33 M_ME_TE_1 Measurand, scaled
integer with
CP56Time2a
3.2.5 Integrated totals
Integrated totals counter values are derived from the IEC 61850 BCR (binary
counter) class. Counter freezing means that the IEC 60870-5-104 stack latches the
current BCR.actVal attribute to itself.
• BCR.actVal
Table 6: Integrated totals
Type ASDU
GI 15 M_IT_NA_1 Integrated totals
Event 37 M_IT_TB_1 Integrated totals with
CP56Time2a
2NGA001859 A Vendor-specific implementation
REX615
IEC 60870-5-104 Communication Protocol Manual
17
