IEC17000245 V1 EN-US
Figure 22: Restoring the previous value
5.1.9.2 Editing string values
AMU0600416 v9
Unicode characters that are not found on the on-screen keyboard can be used if the
string is edited in PCM600. This string can be shown and edited on the HMI but if a
character that is not found on the on-screen keyboard is deleted it cannot be
retrieved using the HMI.
1. Activate the setting mode and select a setting.
When editing string values, the cursor moves to the first character.
2.
Press
to open the editor.
An on-screen keyboard is shown on the HMI.
IEC15000062 V1 EN-US
Editing can be aborted at any time by pressing or by using the Cancel button on the on-
screen keyboard.
3.
Press or to select the edited string and press or to move the cursor.
1MRK 500 131-UEN Rev. C Section 5
Using the HMI
Switchgear control unit SAM600-IO 33
Operation manual
© 2017 - 2021 Hitachi Power Grids. All rights reserved
