ABB 8
1MAC251744 -PG Rev. A
Issued: 03.01.2010
Motor Protection
REM615 ANSI
Product Version 2.0
5. Supported ABB
solutions
ABB’s 615 series protection and control IEDs
together with the COM600 Station Automation
device constitute a genuine IEC 61850 solution for
reliable power distribution in utility and industrial
power systems. To facilitate and streamline the
system engineering ABB’s IEDs are supplied with
Connectivity Packages containing a compilation of
so ware and IED-speci c information including
single-line diagram templates, a full IED data model
including event and parameter lists. By utilizing
the Connectivity Packages the IEDs can be readily
con gured via the PCM600 Protection and Control
IED Manager and integrated with the COM600
Station Automation device or the MicroSCADA Pro
network control and management system.
 e 615 series IEDs o er native support for the IEC
61850 standard also including horizontal GOOSE
messaging. Compared with traditional hard-wired
inter-device signaling, peer-to-peer communication
over a switched Ethernet LAN o ers an advanced
and versatile platform for power system protection.
Fast so ware-based communication, continuous
supervision of the integrity of the protection and
communication system, and inherent  exibility for
recon guration and upgrades are among the distinctive
features of the protection system approach enabled by
the full implementation of the IEC 61850 substation
automation standard.
At the substation level COM600 utilizes the data
content of the design level IEDs to o er enhanced
substation level functionality. COM600 features a
web-browser based HMI providing a customizable
graphical display for visualizing single line mimic
diagrams for switchgear design solutions. To
enhance personnel safety, the web HMI also enables
remote access to substation devices and processes.
Furthermore, COM600 can be used as a local data
warehouse for technical documentation of the
substation and for network data collected by the
IEDs.  e collected network data facilitates extensive
reporting and analyzing of network fault situations
using the data historian and event handling features of
COM600.
COM600 also features gateway functionality
providing seamless connectivity between the
substation IEDs and network-level control and
management systems such as MicroSCADA Pro and
System 800xA.
Table 3. Supported ABB solutions
Product Version
Station Automation COM600 3.4 or later
MicroSCADA Pro 9.2 SP1 or later
