2.4.1.2 LD0.DNPGGIO1 Parameter setting group control
Table 116: LD0.DNPGGIO1 Parameter setting group control
IEC 61850 name SA name Description Type
LD0.DNPGGIO1
.ActSG1.ctlVal - Setting group 1 On
.ActSG2.ctlVal - Setting group 2 On
.ActSG3.ctlVal - Setting group 3 On
.ActSG4.ctlVal - Setting group 4 On
.ActSG5.ctlVal - Setting group 5 On
.ActSG6.ctlVal - Setting group 6 On
2.4.2 Switchgear functions
2.4.2.1 CTRL.CBCSWI1 Circuit breaker control
Table 117: CTRL.CBCSWI1 Circuit breaker control
IEC 61850 name SA name Description Type
CTRL.CBCSWI1
.Pos.Oper.ctlVal - Circuit breaker control On/Off
2.4.2.2 CTRL.CBCSWI2 Circuit breaker control
Table 118: CTRL.CBCSWI2 Circuit breaker control
IEC 61850 name
SA name Description Type
CTRL.CBCSWI2
.Pos.Oper.ctlVal - Circuit breaker control On/Off
2.4.2.3 CTRL.DCCSWI1 Controllable disconnector (1) control
Table 119: CTRL.DCCSWI1 Controllable disconnector (1) control
IEC 61850 name
SA name Description Type
CTRL.DCCSWI1
.Pos.Oper.ctlVal - Disconnector control On/Off
2.4.2.4 CTRL.DCCSWI2 Controllable disconnector (2) control
Table 120: CTRL.DCCSWI2 Controllable disconnector (2) control
IEC 61850 name
SA name Description Type
CTRL.DCCSWI2
.Pos.Oper.ctlVal - Disconnector control On/Off
1MRS757660 A Section 2
DNP3 data mappings
RET620 53
Point List Manual
