ABB REX 521 Technical Reference Manual, General

68
1MRS 751108-MUM
Protection Relay
Technical Reference Manual, General
REX 521
Class 2 measurand sets
Explanations to the Table 9.5.-3:
The measurand sets 2, 3, 5, 6, 7, 8 and 9 are not relevant for the Basic and Medium
versions of the protection relay. The default measurand set is 11.
*) According to the device function type
Table 9.5.-2 Commands
1
1.When controlling the output relays by using the IEC_103 protocol, the interlocking of
the standard configuration is bypassed. It is not allowed to use the same output relay as
a tripping contact and as an IEC_103 controlling object simultaneously
Commands St Ftyp
Info
Num
Typ
COT
cmd
COT
resp
I<->0 CB1: control CB1 B 240 160 20 20 20,21
Output relay 1 control (HSPO1) P 251 27 20 20 20,21
Output relay 2 control (PO1) P 251 28 20 20 20,21
Output relay 3 control (PO2) P 251 29 20 20 20,21
Output relay 4 control (PO3) P 251 30 20 20 20,21
Output relay 5 control (SO1) P 251 31 20 20 20,21
Output relay 6 control (SO2) P 251 32 20 20 20,21
SetNo
Class 2 measurand set No (1...11)
St
Status
A According to the IEC 60870-5-103 standard
P Private definition
Meas
Measurand class I or II
FuncType/
InfoNum
Class 2 Frame identification
If stated as *), the signal type Ftyp corresponds with the unit function
type. Unit function type may be adjusted via the Function type
parameter.
Num data
The number of the data values in the class 2 message data part
Typ
Meas type 3 or 9 (when the definition is private, meas type 9 is used)
Data
Measurement data in class 2 message data part:
Not available: -
!
!
Table 9.5.-3 Recommended Class 2 measurand sets
Set No St Meas
Func
Type
Info
Num
Num
data
Typ Data
1 Meas I: 144 A I *) 144 1 3
IL2
2 Meas I: 145 A I *) 145 2 3
IL2, U12
3 Meas I: 146 A I *) 146 4 3
IL1, U12, P, Q
4 Meas I: 147 A I *) 147 2 3
Io, Uo
5 Meas II: 148 A II *) 148 9 9
IL1, IL2, IL3, U1, U2, U3, P, Q, f
6 Meas II: ABB1 P II 134 137 16 9
IL1, IL2, IL3, Io, -, -, -, U12, U23, U31, P, Q, f, -, -, pf
7 Meas II: ABB2 P II 134 137 16 9
IL1, IL2, IL3, Io, U1, U2, U3, -, -, -, P, Q, f, -, -, pf
8 Meas II: ABB3 P II 135 137 12 9
IL1, IL2, IL3, U1, U2, U3, Io, Uo, P, Q, pf, f
9 Meas II: ABB4 P II 135 138 12 9
IL1, IL2, IL3, U12, U23, U31, Io, Uo, P, Q, pf, f
10 Meas II: Basic P II 135 139 4 9
IL1, IL2, IL3, Io
11 Meas II: Medium P II 135 140 5 9
IL1, IL2, IL3, Io, Uo
