Create the RIO600 in PCM600, use the
RIO600 Connpack and select online or
offline configuration
Online mode
Select and assign
the HW slot
RIO600 ConnPack scans the ‘powered up’
RIO600 and ascertains the hardware
configuration
Set the parameters of
RIO600 modules
RIO600 ConnPack automatically instantiates one LN GGIO
for every BI module, comprising DOs equaling number of
channels and also creates the datasets comprising all the
BI channel status and health information
Export the SCD file to the
IET600 tool
Enter the GoCB parameters for RIO600
and do subscriber mapping
Export the SCD file to
PCM600
Map the I/O using SMT
in PCM600
Select the write operation and download
the configuration into RIO600
Use the Web client to view parameter
settings and other operational data of the
RIO600 device
No
Yes
To Next Page
