1. Information about the functions
of the SACE PR010/T unit
(release 7.7)
The SACE PR010/T unit can be connected to different types of ABB SACE electronic relays
(also known as DUT) in order to perform tests, program and read parameters.
Using a cable and adapters, the PR010/T unit can be connected to the test connector of the relay,
installed at the front. A list of relays compatible with the PR010/T unit is given below, along with
the type of cables required for the connection.
RELAY (1) CIRCUIT-BREAKER TYPE OF CABLE ADAPTER
PR111
EMAX A X
PR111/VF
EMAX VF A X
PR112
(2) (4)
EMAX A / B X
PR113
(4)
EMAX B
PR212
(3)
ISOMAX C
PR212MP
(3)
ISOMAX C
PR222
(4) (5)
TMAX T4-T5-T6 D
PR222MP
TMAX T4-T5-T6 D
PR223DS
(5)
TMAX T4-T5-T6 D
PR223EF
(5)
TMAX T4-T5-T6 D
PR232
TMAX T7 E X
PR232-T8
TMAX T8 E X
PR331
TMAX T7-T8 / EMAX X1 E X
PR332
TMAX T7-T8 / EMAX X1 E X
PR333
EMAX X1 E X
PR121
NEW EMAX E
PR122
NEW EMAX E
PR123
NEW EMAX E
PR122DC
EMAX DC E
PR123DC
EMAX DC E
NOTES
1
In all IEC and UL releases available, unless there is an additional note
2
Consult the details in the next chapter for connection to PR112
3
Connection only available for versions with a front test connector
4
Auxiliary voltage must be available for the PD relay versions
5
When the PR010T unit is connected, a relay normally connected to an external system temporarily
interrupts the communication with this latter
