2. SACE PR11x/PR212x/PR222x/
PR223x protection relays
2.1 Operating mode menu
All the SACE relays belonging to this group partly or fully share certain of the functions and
characteristics.
Considering the main menus, all unit can access the following menus:
• Test: tests of the protections, trip mechanism and high signals.
• Reading: monitoring of the current values, relay and circuit-breaker parameters, trip history
and other information in general.
• Programming: editing of the relay and circuit-breaker parameters, the protection status and
other configuration data.
CAUTION
During access to the menus, an error message could appear for certain of
the relays, if the CB type and TA current rating have not yet been defined.
2.2 Test
The tests available with the various different SACE relays are listed in the table below.
PR111 PR111/VF PR112 PR113 PR212 PR212MP PR222 PR222MP PR223EF PR223DS
TEST (1)
Trip Test
XX XXXXX
Manual protections
XXXXX
(2) X(2) X(2) X(2) XX
Automatic protections XX
XXX
(2) X(2) X(2) X(2) XX
Set/reset Coil
XX
Iinst protection
XXX
NOTES
1
Perform the trip test with the circult-breaker Closed and the protection test with the circuit-breaker Open.
2
The automatic test and manual test with the default parameters can only be performed by using the Electronic
SET configuration for the relay (ELT) by means of the relative dip switch.
