1.1.4 CABLE D
The diagram shows an example of connection to a PR223EF relay.
1.1.5 CABLE E
The diagram shows an example of connection to a PR331 relay with the aid of a mechanical
adapter.
1.2 Menu tree
When connected to the SACE relay, the PR010/T relay allows all the available functions and
information to be accessed by means of a tree menu.
For some of the relays, the structure of the tree menu (and the available functions and
information) is very similar: they can thus be grouped into two categories, as shown in the table
below:
RELAY CIRCUIT-BREAKER CHAPTER
PR111; PR111/VF; PR112; PR113
EMAX
3
PR212; PR212MP
ISOMAX
PR222; PR222MP; PR223EF;
PR223DS
TMAX T4-T5-T6
PR232; PR232-T8; PR331; PR332;
PR333
TMAX T7-T8 /
EMAX X1
4
PR121; PR122; PR123
NEW EMAX
PR122DC; PR123DC
EMAX DC
