TECHNICAL AND APPLICATION GUIDE 25
—
Available frame types
Auxiliary frames
—
Dimensions
Frame Width (in) Height (in)* Depth (in)
All frames 86.5 or 93.5
Options
• Space heaters
Description
The two-high auxiliary frame consists of compart-
ments with a 19-inch instrument compartment in
between multiple auxiliary devices per frame.
All ratings
—
01 CPT=control power
transformer
—
02 LVC=low voltage
compartment/instru-
ment compartment
—
03 PT=potential
transformer
—
04 DOF=drawout fuse
