ABB T566609 - Page 105

Operation Manual / TPL67-C.. - TPL71-C..
Di
sassembly and assembly
8
Table of tightening torques
8.9
Page 103
© Copyright 2016 ABB. All rights reserved.
April 2016 HZTL2488_EN Revision C
Part number
TPL67-C
TPL71-C
1 82005 M16x1.5
45
M16x1.5
45
3
72002
M10
50
M12
80
4 72027
with washer
M14
95
M16
125
5
72029
with washer
M14
30
M16
30
6 61037 M16
110
M18
160
6a
61090
M16
10
M18
15
7 61036 M16
30
M18
40
8
61059
M16
200
M18
280
9 42059 M12
80
M16
180
17
61044
M12
80
M14
130
21 61056 M12
105
M14
130
29
86505
M18x1.5
150
M18x1.5
150
Tightening torques [Nm]
