Operation Manual / TPL67-C.. - TPL71-C..
Page 48
© Copyright 2016 ABB. All rights reserved.
April 2016 HZTL2488_EN Revision C
If the speed sensor is not fitted on the turbocharger, the following proce-
dure must be adopted to fit it:
Engine and turbocharger are not running.
The turbocharger lubricating system is switched off.
Remove screw plug (42047) from bearing casing.
The position of the screw plug for measuring the speed is marked "
"
on the bearing casing.
Screw in speed sensor (86505) as far as it will go and tighten to torque
specified in table. (See chapter Table of tightening torques.)
Connect speed sensor using cable connector (86515).
