3.5.4 DC plate
A Terminal X4 C Ethernet connector
Part Function
Terminal X4 To connect the interlock and DC guard cables
Ethernet connector To connect the Ethernet cable between power
cabinet and charge post
Earthing terminal To connect the ground wire or shield mesh
Description
6AGA000032-0115-EN | 004 23
B Earthing terminal
A
B
