XT5 3p-4p
2
In = 400 A
I1 = 400 x (0,4+0,08+0,32)= 320A
t1= 12 s @240 A (3I )
1
Esempio:
Example:
I2 =400 x (1,5+2)=1400A
In=400 A
Esempio:
t2
Example:
= 0,2 s @ In>I
2
t
L
t1
I
I3
I1
I
I
t
S
L
I2
I1
=
Settaggio di default
Default setting
Default-Einstellung
Configuration par défauit
Ajuste de default
默认设置
LED Color CONDITION Run time
Green LED ON (fixed) = Device active
L Yellow LED Fixed = L pre alarm (0,9 * I1 < I < 1,2 * I1)
L Red LED Blinking = L alarm (I > 1,2 * I1)
S Red LED Blinking = S alarm (I > I2)
L | S | I Red
LED Blinking = Parameters inconsistency - L = S or L = I.
LED Blinking without Parameters inconsistency = generic fault (please contact ABB)
