Operation Manual / TPL85-B14/-B15/-B16
Cleaning the filter silencer
© Copyright 2016 ABB. All rights reserved.
May 2016 HZTL2491_EN Revision B
Assemble insert units (E) by putting absorption segments (81136) into
cover sheet metal (81137).
Bend back cover sheet metal to original shape.
Put insert units (E) into guide grooves in filter silencer body (81135).
In the case of an insert unit (E), the water injection line must first be re-
moved if a cleaning medium vessel is fitted to the filter silencer (optional
depending on turbocharger type). (See also following section Removing
cleaning pipe.)
Fit cover grids (81266) and connecting strips (81268) to filter silencer
body (81135).
Run tension bands (81270) through lugs (eyelets) on connecting
strips.
Tighten all tension bands at locks (81271).
Fit filter strip (81265).
