TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
90
Table 5-17. Fast Status Modbus Address Map Definition
Register
Address
Item Description
40170 Fast Status
Bit 0 - 5 Reserved ( Lsb)
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 – 15 Product ID (Msb)
Unsigned 16 Bit
00 0101 = 07 HEX Division Code
40171 Fast Status
Bit 0 Division Code (Lsb)
Bit 1 Division Code
Bit 2 Division Code
Bit 3 Division Code
Bit 4 Division Code
Bit 5 Division Code
Bit 6 Unreported Record
Bit 7 Reserved
Bit 8 Heartbeat Timer
Bit 9 Heartbeat Timer
Bit 10 Heartbeat Timer
Bit 11 Heartbeat Timer
Bit 12 Heartbeat Timer
Bit 13 Heartbeat Timer
Bit 14 Heartbeat Timer
Bit 15 Heartbeat Timer (Msb)
Unsigned Integer 16 Bit
Reserved
Reserved
Reserved
Reserved
Reserved
00 1110 = 0E HEX left justified
1= Unreported Operation Record
Reserved
These bits update once every 100
mS to indicate that the
communication card is still updated
by the central TPU processor.
Communication Event Log (8 Registers Defined)
Whenever a communication error occurs, the TPU2000/TPU2000R generates an exception response to the
rejected command. Registers 40172 through 40179 contains information on the last communication error
experienced via the front communication port, rear INCOM port or the RS232/485 ports resident on the relay’s
communication card. Table 5-18 lists the register definition for the event log.
Table 5-18. Communication Error Event Log
Address Item Definition
40172 Last Comm Port Error Unsigned Integer
0 = Modbus Plus (Type 6 or 7 Card Only TPU2000R)
1 = INCOM
2 = RS232
3 = RS485
4 = Ethernet
40173 Last Comm Error
Command
Unsigned Integer/ Word Byte Decode
If Modbus or Modbus Plus, register contains Modbus Command. If
INCOM or Standard Ten Byte, register contains Command +
Subcommand in upper lower byte decode.
40174 Last Comm Error Register
Request
Unsigned Integer
Last Requested Address on Comm error read/write request.
40175 Last Comm Error Type Unsigned Integer
1= Invalid Password
2 = Checksum Error
3 = Block/Register Range Invalid
4 = Block/Register attempted to be accessed invalid
5 = Range of data attempted to be accessed invalid
