ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
8
1 Horizontal Unit Mounting – Front panel LCD interface is included.
5 Vertical Unit Mounting – No front panel LCD interface.
6 Vertical Unit Mounting – Front panel LCD interface is included.
IF PART
NUMBER
POSITION “Z
” IS
THE TPU2000R HAS AN INSTALLED OPTION
For unit 5 8 8 X X X Y Z
– X X X X Q ( X = Don’t Care)
(COMMUNICATION PHYSICAL INTERFACE OPTION)
0 RS232 (COM 1) Non-Isolated Port is active on the unit.
1 RS232 (COM 2) Isolated Port Only is active on the unit. (SEE NOTE)
2 RS485 (AUX COM PORT) and RS232 (COM 3) Ports on Option Card.
3 INCOM (AUX COM PORT) and RS485 (AUX COM PORT) Ports on Option Card.
4 INCOM (AUX COM PORT) and RS485 (AUX COM PORT) Ports on Option Card.
5 RS485 (AUX COM PORT) Port On Option Card.
6 Modbus Plus Port (COM 3) on the Option Card.
7 Modbus Plus (COM 3) and RS485 (AUX COM PORT) on the Option Card.
8 RS485 (COM 3) and RS485 (AUX COM PORT) Ports on the Option Card.
E Ethernet Fiber Optic and Copper Option Card (Available on the 2 Winding TPU
Unit Only)
NOTE: * = If the option denoted in part number position “Y” is a 0 or 5, the COM 2
port is enabled, if the option denoted in part number position “Y” is a 2 or 6 the
COM 2 Port is disabled.
IF PART
NUMBER
POSITION “Q
” IS
THE TPU2000R HAS AN INSTALLED OPTION
For unit 5 8 8 X X X Y Z – X X X X Q
(X = Don’t Care)
(COMMUNICATION PHYSICAL INTERFACE OPTION)
0 STANDARD TEN BYTE
1 DNP 3.0
4 Serial Modbus/Modbus Plus/TCP/IP Modbus (Depending on hardware interface
selected in Position Z)
Table 2-4. TPU2000R Communication Card Matrix for Unit 5 8 8 X X X Y Z – X X X X Q
“Z”
Digit
“Q”
Digit
COM 1
RS232
COM 2
RS232
COM 3 AUX COM
RS485
INCOM Time
Synch
0 0 Note 1 Standard 10 Byte
1 0 Note 1 Standard 10 Byte RS232
2 0 Note 1 Standard 10 Byte RS232 Standard 10 Byte IRIG B
2 1 Note 1 Standard 10 Byte or
DNP 3.0 RS232
Standard 10 Byte
or DNP 3.0
2 4 Note 1 Standard 10 Byte or
Modbus RS232
Standard 10 Byte
or Modbus
IRIG B
3 0 Note 1 Available IRIG B
4 0 Note 1 Standard 10 Byte Available IRIG B
4 1 Note 1 DNP 3.0 Available IRIG B
4 4 Note 1 Modbus Available IRIG B
5 0 Note 1 Standard 10 Byte
6 4 Note 1 Standard 10 Byte Modbus Plus
7 4 Note 1 Modbus Plus Standard 10 Byte
8 0 Note 1 Standard 10 Byte RS485 Standard 10 Byte IRIG B
8 1 Note 1 Standard 10 Byte or
DNP 3.0 RS485
Standard 10 Byte
or
DNP 3.0
8 4 Note 1 Standard 10 Byte or
Modbus RS485
Standard 10 Byte
or
Modbus
IRIG B
E 4 Note 1 TCP/IP Modbus
Ethernet Copper
SNTP
