TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
100
Register
Address
Item Description
Year 00<= Range <= 99
40816 Peak Demand KVAR Hours (Phase B)
Month
Least Significant Byte 8 Bits
00<= Range <= 12
40817 Peak Demand KVAR Hours (Phase B)
Day
Most Significant Byte 8 Bits
00<= Range<= 31
40817 Peak Demand KVAR Hours (Phase B)
Hour
Most Significant Byte 8 Bits
00<= Range <= 23
40818 Peak Demand KVAR Hours (Phase B)
Minute
Most Significant Byte 8 Bits
00<= Range <= 59
40818 Reserved Byte Reserved
40819 KVAR Hours (Phase C) Peak Demand Signed 32 Bit High Order Word MSW
40820 KVAR Hours (Phase C) Peak Demand Signed 32 Bit Low Order Word LSW
40821 Peak Demand KVAR Hours (Phase C)
Year
Most Significant Byte 8 Bits
00<= Range <= 99
40821 Peak Demand KVAR Hours (Phase C)
Month
Least Significant Byte 8 Bits
00<= Range <= 12
40822 Peak Demand KVAR Hours (Phase C)
Day
Most Significant Byte 8 Bits
00<= Range<= 31
40822 Peak Demand KVAR Hours (Phase C)
Hour
Most Significant Byte 8 Bits
00<= Range <= 23
40823 Peak Demand KVAR Hours (Phase C)
Minute
Most Significant Byte 8 Bits
00<= Range <= 59
40823 Reserved Byte Reserved
40824 KVAR Hours (3 Phase) Peak Demand Signed 32 Bit High Order Word MSW
40825 KVAR Hours (3 Phase) Peak Demand Signed 32 Bit Low Order Word LSW
40826 Peak Demand KVAR Hours (3 Phase)
Year
Most Significant Byte 8 Bits
00<= Range <= 99
40826 Peak Demand KVAR Hours (3 Phase)
Month
Least Significant Byte 8 Bits
00<= Range <= 12
40827 Peak Demand KVAR Hours (3 Phase)
Day
Most Significant Byte 8 Bits
00<= Range<= 31
40827 Peak Demand KVAR Hours (3 Phase)
Hour
Most Significant Byte 8 Bits
00<= Range <= 23
40828 Peak Demand KVAR Hours (3 Phase)
Minute
Most Significant Byte 8 Bits
00<= Range <= 59
40828 Reserved Byte Reserved
The minimum demand table is as follows:
Table 5-24. Minimum Demand Register Map for the TPU2000R and TPU2000
Register
Address
Item Description
40897 Minimum Demand Current Phase A Unsigned 32 Bit High Order Word MSW
40898 Minimum Demand Current Phase A Unsigned 32 Bit Low Order Word LSW
40899 Minimum Demand Current Phase A Year Most Significant Byte 8 Bits
00<= Range <= 99
40899 Minimum Demand Current Phase A Month Least Significant Byte 8 Bits
00<= Range <= 12
40900 Minimum Demand Current Phase A Day Most Significant Byte 8 Bits
00<= Range<= 31
40900 Minimum Demand Current Phase A Hour Most Significant Byte 8 Bits
00<= Range <= 23
40901 Minimum Demand Current Phase A Minute Most Significant Byte 8 Bits
00<= Range <= 59
