TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
198
Register
Address
Item Description
63235 150G-3 Time Delay Unsigned 16 Bits
0<=Range<=9.99 * 100
63236 Disturb 3 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=5 *10
63237 Level Detector-1 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=20 *10 , 201 = Disable
Table 5-68. Alt 1 Settings Register Definition
Register
Address
Item Description
61152 SPARE_1
61153 Execute Register
0 = No Action
1 = Update Registers
2 = Refresh Registers
Unsigned 16 Bits
61154 Access Password ASCII – 2 Characters Leftmost Digits
61155 Access Password ASCII – 2 Characters Rightmost Digits
61156 SPARE_2
61157 87T Curve Type Unsigned Integer 16 Bits
61158 87T Minimum I Operate Unsigned 16 Bits
0.2 <=Range <=1.0 (X10)
61159 87T Percent Restraint 15<=Range<=60
61160 87T Restraint Mode Unsigned Integer 16 Bits
Refer to Mode Selection Table
61161 87T 2
nd
Harmonic Restraint Unsigned Integer 16 Bits
7.5<=Range<=25 (X10)
61162 87T 5
th
Harmonic Restraint Unsigned Integer 16 Bits
15<=Range<=40 (X10)
61163 87T All Harmonic Restraint Unsigned Integer 16 Bits
15<=Range<=40 (X10)
61164 87H Tap X Byte Unsigned Integer 16 Bits
6 <=Range<=20 (X10)
61165 87T-1 Amp Unsigned Integer 16 Bits
2<=Range<=9 (X10)
0.4<=Range<=1.8 (X50)
61166 51P-1 Curve Select (TYPE I ) Unsigned 16 Bits
Range 0-12 (See Text Above)
61167 51P-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61168 51P-1 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 (X20) Time Dial
0<=Range<=10 (X20) Time Delay
61169 50P-1 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61170 50P-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61171 50P-1 Time Dial/Time Delay Unsigned 16 Bits
Dial *10
Delay * 100
61172 150P-1 Curve Select Unsigned Integer 16 bits
See Table Above
61173 150P-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
To Next Page
