TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
212
1 = Update Registers
2 = Refresh Registers
61794 Access Password ASCII – 2 Characters Leftmost Digits
61795 Access Password ASCII – 2 Characters Rightmost Digits
61796 SPARE_2
61797 Hour Unsigned 16 Bit Hour Range 0-23
61798 Minute Unsigned 16 Bit Minute Range 0-59
61799 Second Unsigned 16 Bit Second Range 0-59
61800 Day Unsigned 16 Bit Day Range 1-31
61801 Month Unsigned 16 Bit Month Range 1-12
61802 Year Unsigned 16 Bit Year Range 00-99
ULO Connection Settings and User Names
The TPU2000/TPU2000R has internal Soft Bits, which are used for logical boolean programming. Please
reference the IL bulletin for a more detailed explanation of the use of these bits. One should also realize that
Connected means that the ULO X is logically fed back through the appropriate FBX to the appropriate ULIX,
where X is a number from 1 to 9.
Table 5-78 describes the register designation.
Registers 61924 designate whether the ULO is connected to the corresponding ULI. Registers 61926 through
61958 contain the 8 characters, which make up the ULO Name.
Table 5-78. ULO Table Map For Character Name Assignment
Address Item Description
61920 SPARE_1
61921 Execute Register
0 = No Action
1 = Update Registers
2 = Refresh Registers
Unsigned 16 Bits
61922 Access Password ASCII – 2 Characters Leftmost Digits
61923 Access Password ASCII – 2 Characters Rightmost Digits
61924 SPARE_2
61925 ULO/ULI Connection
Designation
Bit 0 = ULO9
Bit 1 = ULO8
Bit 2 = ULO7
Bit 3 = ULO6
Bit 4 = ULO5
Bit 5 = ULO4
Bit 6 = ULO3
Bit 7 = ULO2
Bit 8 = ULO1
Bit 9 = Reserved
Bit 10 = Reserved
Bit 11 = Reserved
Bit 12 = Reserved
Bit 13 = Reserved
Bit 14 = Reserved
Bit 15 = Reserved
Unsigned Integer 16 Bit
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
0 = Connected 1 = Not Con.
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
61926 ULO 1 Rightmost 2 Characters 2 Digit ASCII Characters
61927 ULO 1 Characters 2 Digit ASCII Characters
61928 ULO 1 Characters 2 Digit ASCII Characters
61929 ULO 1 Leftmost 2 Characters 2 Digit ASCII Characters
To Next Page
