TPU2000/2000R Modbus/Modbus Plus Automation Guide
83
13: 40013 Offset Bipolar (12) 40534 (32/Signed) 1000 (Power) Phase A VARs
14: 40014 Offset Bipolar (12) 40536 (32/Signed) 1000 (Power) Phase B VARs
15: 40015 Offset Bipolar (12) 40538 (32/Signed) 1000 (Power) Phase C VARs
16: 40016 Unipolar (16) 40158 (16/Unsigned) 1 (Normal) Phase CT Ratio
17: 40017 Unipolar (16) 40159 (16/Unsigned) 1 (Normal) PT Ratio
18: 40018 Offset Bipolar (12) 40399 (16/Unsigned) 10 (Current) Load Current N
19: 40019 Unipolar (16) 40556 (32/Signed) 10000
(Normal)
Pos 3 Phase
kWatthours (High)
20: 40020 Unipolar (16) 40556 (32/Signed) 10000
(Remainder)
Pos 3 Phase
kWatthours (Low)
21: 40021 Neg Unipolar (16) 40556 (32/Signed) 10000
(Normal)
Neg 3 Phase
kWatthours (High)
22: 40022 Neg Unipolar (16) 40556 (32/Signed) 10000
(Remainder)
Pos 3 Phase
kWatthours (Low)
23: 40023 Unipolar (16) 40558 (32/Signed) 10000
(Normal)
Pos 3 Phase
kVARhours (High)
24: 40024 Unipolar (16) 40558 (32/Signed) 10000
(Remainder)
Pos 3 Phase
kVARhours (Low)
25: 40025 Neg Unipolar (16) 40558 (32/Signed) 10000
(Normal)
Neg 3 Phase
kVARhours (High)
26: 40026 Neg Unipolar (16) 40558 (32/Signed) 10000
(Remainder)
Neg 3 Phase
kVARhours (Low)
27: 40027 Unipolar (16) 40562 (16/Unsigned) 1 (Normal) System Frequency
28: 40028 No Default No Default No Default Spare
29: 40029 No Default No Default No Default Spare
30: 40030 No Default No Default No Default Spare
31: 40031 No Default No Default No Default Spare
32: 40032 No Default No Default No Default Spare
An explanation of some of the above default mappings are offered as a guide to understanding the scaling
methodology implementation. Figure 5-31 illustrates the scaling procedure for remapped registers 40001 through
40032 Registers 257, 259, and 261 (as detailed in Table 5-11 above) contain the MMI reported current values to
be remapped and re-scaled to 12 bit Offset Bipolar Values.
E
C
NORMAL
FAIL
PICKUP
RECLOSER OUT
SYSTEM RESET
TIME
INS TA NT A N E O US
FREQUENCY
NEGATIVE SEQUENCE
TARGET RESET
STATUS TARGETS
A
B
C
N
DPU
2000R
Network
Partner
V1.0
TPU2000R
32
Mappable
Registers
400001
400002
400003
400004
400005
400032
Ia Current Mag.
Ib Current Mag.
Ic Current Mag.
OFFSET BIPOLAR
12 bit resolution
0 = (-) Full Scale
(12 bits -1)
2 - 1 = 2047 = 0
(12 bits)
2 - 1 = 4095 = (+) Full Scale
REFERENCE TABLE 2
(+) Full Scale = Scale * CT phase = 10* 100 = 1000
(-) Full Scale = - Scale * CT
Phase = - 10 * 100 =
- 1000
0 Amperes
RTU or Host Reads 0
RTU or Host Reads 2047
RTU or Host Reads 4095
DPU 2000(R) Register Contents
in Register 40002, 40003, or 40004
DPU 2000(R) MMI Display
or Register Contents of 40257, et al
Figure 5-31. Register Scaling Default Example
The mathematics to determine the reported value to the host is illustrated in Figure 5-31 and using Equation 5
above.
