TPU2000/2000R Modbus/Modbus Plus Automation Guide
197
Register
Address
Item Description
Dial *10
Delay * 100
63212 150P-3 Curve Select Unsigned Integer 16 bits
See Table Above
63213 150P-3 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
63214 150P-3 Time Dial Unsigned 16 Bits
0<=Range<=9.99 * 100
63215 46-3 Curve Select Byte Unsigned Integer 16 bits
See Table Above
63216 46-3 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
63217 46-3 Time Dial/Time Delay Unsigned 16 Bits
1<=Range<=12 * 10
0.2<=Range<= 0.4 *50
63218 51N-3 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
63219 51N-3 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
63220 51N-3 Time Dial Unsigned 16 Bits
1<=Range <=20 /Delay Byte
0<=Range<=10 * 20 51N Time Multiplier
63221 50N-3 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
63222 51N-3 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
63223 51N-3 Time Dial/Delay Setting Unsigned 16 Bits
Time Dial * 10
Delay * 100
63224 150N-3 Curve Select (TYPE II) Unsigned Integer 16 bits
See Table Above
63225 150N-3 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
63226 150N-3 Time Delay Unsigned 16 Bits
0<=Range<=9.99 * 100
63227 51G-3 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
63228 51G-3 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
63229 51G-3 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 * 20 : Time Dial
0<=Range<=10 * 20 : Time Delay
63230 50G-3 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
63231 51G-3 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
63232 51G-3 Time Dial/Delay Setting Unsigned 16 Bits
Time Dial * 10
Delay * 100
63233 150G-3 Curve Select (TYPE II) Unsigned Integer 16 bits
See Table Above
63234 150G-3 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
To Next Page
