TPU2000/2000R Modbus/Modbus Plus Automation Guide
199
Register
Address
Item Description
61174 150P-1 Time Dial Unsigned 16 Bits
0<=Range<=9.99 * 100
61175 46-1 Curve Select Byte Unsigned Integer 16 bits
See Table Above
61176 46-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61177 46-1 Time Dial/ Time Delay Unsigned 16 Bits
1<=Range<=12 * 10
0.2<=Range<= 0.4 *50
61178 51N-1 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61179 51N-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61180 51N-1 Time Dial Unsigned 16 Bits
1<=Range <=20 /Delay Byte
0<=Range<=10 * 20 51N Time Multiplier
61181 50N-1 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61182 51N-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61183 51N-1 Time Dial/Delay Setting Unsigned 16 Bits
Time Dial * 10
Delay * 100
61184 150N-1 Curve Select (TYPE II) Unsigned Integer 16 bits
See Table Above
61185 150N-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61186 150N-1 Time Delay Unsigned 16 Bits
0<=Range<=9.99 * 100
61187 87T-2 Tap Amp Setting Unsigned 16 Bits
2<=Range<=9 Amperes * 10
0.4<=Range <=1.8 * 50
61188 51P-2 Curve Select Byte (TYPE I) Unsigned 16 Bits (See Text Above)
61189 51P-2 Pickup Amp/OA Unsigned 16 Bits
1<=Range<=12 *10
0.2<=Range<=2.4 * 50
61190 51P-2 Time Dial/Delay Setting Unsigned 16 Bits
Dial : 1<=Range<=10 *20
Delay : 0<=Range<=10 * 20
61191 51P-2 Curve Select (TYPE I ) Unsigned 16 Bits
Range 0-12 (See Text Above)
61192 51P-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61193 51P-2 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 (X20) Time Dial
0<=Range<=10 (X20) Time Delay
61194 51P-2 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61195 51P-2 Pickup X Amps Unsigned 16 Bits
0.5<=Range<=20 Amp * 10 (See Note)
61196 51P-2 Time Dial/Time Delay Unsigned 16 Bits
Time Dial * 10
Time Delay * 20
