TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
200
Register
Address
Item Description
61197 46-2 Curve Select (TYPE I) Unsigned Integer 16 bits
See Table Above
61198 46-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61199 46-2 Time Dial/Time Delay Unsigned 16 Bits
1<=Range<=10 * 20
0<=Range<= 10 *20
61200 51G-2 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61201 51G-2 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61202 51G-2 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 * 20 : Time Dial
0<=Range<=10 * 20 : Time Delay
61203 50G-2 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61204 51G-2 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61205 51G-2 Time Dial/Delay Setting Unsigned 16 Bits
Time Dial * 10
Delay * 100
61206 150G-2 Curve Select (TYPE II) Unsigned Integer 16 bits
See Table Above
61207 150G-2 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61208 150G-2 Time Delay Unsigned 16 Bits
0<=Range<=9.99 * 100
61209 Disturb 2 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=5 *10
61210 Level Detector-1 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=20 *10 , 201 = Disable
61211 Level Detector-1 Pickup X Unsigned Integer 16 Bits
0.5<= Range<=20 *10 , 201 = Disable
61212 Unit Configuration Byte Unsigned Integer 16 Bits (rightmost bit)
Bit 0: Neutral Tap Range Wdg1 (lsb)
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 1: Neutral Tap Range Wdg1
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 2: Neutral Tap Range Wdg1
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 3: Neutral Tap Range Wdg1
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 4: User Definable Curves
Bit 5: Reserved
Bit 6: Neutral Tap Range Wdg 3
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 7: Phase Tap Range Wdg3
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 8: MOCT’s on Wdg1
(1= None 0= MOCT Present)
Bit 9: MOCT’s on Wdg1
(1= None 0= MOCT Present)
Bit 10: Reserved
Bit 11: Reserved
