ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
108
Bit 15 = 87T
Bit 14 = 87H
Bit 13 = 51P-1
Bit 12 =51P-2
Bit 11 = 51N-1
Bit 10 =
51G-2 (Note 2)
51N-2 (Note 3)
Bit 9 = 50P-1
Bit 8 = 50P-2
Bit 7 = 50N-1
Bit 6 =
50G-2 (Note 2)
50N-2 (Note 3)
Bit 5 = 150P-1
Bit 4 = 150P-2
Bit 3 = 150N-1
Bit 2 = 150G-2
Bit 1 = 46-1
Bit 0 = 46-2
Two or Three Winding 3 Phase % Differential Current Control
Enabled (msb leftmost)
Two or Three Winding 3 Phase Instantaneous Differential
Current Control Enabled
Winding 1 Phase Time Overcurrent Control Enabled
Winding 2 Phase Time Overcurrent Control Enabled
Winding 1 Neutral Time Overcurrent Control Enabled
Winding 2 Ground Time Overcurrent Control Enabled
Winding 2 Neutral Time Overcurrent Control Enabled
1
st
Winding 1 Phase Instantaneous Overcurrent Control
Enabled
1
st
Winding 2 Phase Instantaneous Overcurrent Control
Enabled
1
st
Winding 1 Neutral Instantaneous Overcurrent Control
Enabled
1
st
Winding 2 Ground Instantaneous Overcurrent Control
Enabled
1
st
Winding 2 Neutral Instantaneous Overcurrent Control
Enabled
2
nd
Winding 1 Phase Instantaneous Overcurrent Control
Enabled
2
nd
Winding 2 Phase Instantaneous Overcurrent Control
Enabled
2
nd
Winding 1 Neutral Instantaneous Overcurrent Control
Enabled
2
nd
Winding 2 Ground Instantaneous Overcurrent Control
Enabled
Winding 1 Negative Sequence Control Enabled
Winding 1 Negative Sequence Control Enabled (lsb
rightmost)
41162 Logical Input
Bit 15 = ALT 1
Bit 14 = ALT 2
Bit 13 = ECI 1
Bit 12 = ECI 2
Bit 11 = WCI
Bit 10 =TRIP
Bit 9 = SPR
Bit 8 = TCM
Bit 7 = ULI 1
Bit 6 = ULI 2
Bit 5 = ULI 3
Bit 4 = ULI 4
Bit 3 = ULI 5
Bit 2 = ULI 6
Bit 1 = ULI 7
Bit 0 = ULI 8
Unsigned Integer 16 Bit
Alternate 1 Settings Enabled (msb leftmost)
Alternate 2 Settings Enabled
Event Capture 1 Initiated Enabled
Event Capture 2 Initiated Enabled
Waveform Capture Initiated
Initiate Differential Trip Output Contacts
Sudden Pressure Input Sensed
Trip Coil Monitor Input Sensed
User Logical Input 1 Sensed
User Logical Input 2 Sensed
User Logical Input 3 Sensed
User Logical Input 4 Sensed
User Logical Input 5 Sensed
User Logical Input 6 Sensed
User Logical Input 7 Sensed
User Logical Input 8 Sensed (lsb rightmost)
41163 Logical Input
Bit 15 = ULI 9
Bit 14 = CRI
Bit 13 = Reserved
Bit 12 = Reserved
Bit 11 = Reserved
Bit 10 = Reserved
Bit 9 = Reserved
Bit 8 = Reserved
Bit 7 = Reserved
Bit 6 = Reserved
Bit 5 = Reserved
Unsigned Integer 16 Bits
User Logical Input 8 Sensed (msb leftmost)
Fault and Overcurrent Clear Through Counters Enabled
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
