TPU2000/2000R Modbus/Modbus Plus Automation Guide
111
Bit 0 = IN 1 0 = Open, 1 = Closed (lsb rightmost bit)
41173 Phys Out
Bit 15 = Reserved
Bit 14 = Reserved
Bit 13 = Reserved
Bit 12 = Reserved
Bit 11 = Reserved
Bit 10 = Reserved
Bit 9 = Reserved
Bit 8 = Reserved
Bit 7 = OUT 7
Bit 6 = OUT 6
Bit 5 = OUT 5
Bit 4 = OUT4
Bit 3 = OUT3
Bit 2 = OUT2
Bit 1 = OUT 1
Bit 0 = TRIP
16 Bit Unsigned Integer Physical Output Select Status
Reserved (msb leftmost bit)
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced (lsb rightmost bit)
41174 Phys Out
Bit 15 = Reserved
Bit 14 = Reserved
Bit 13 = Reserved
Bit 12 = Reserved
Bit 11 = Reserved
Bit 10 = Reserved
Bit 9 = Reserved
Bit 8 = Reserved
Bit 7 = OUT 7
Bit 6 = OUT 6
Bit 5 = OUT 5
Bit 4 = OUT4
Bit 3 = OUT3
Bit 2= OUT2
Bit 1 = OUT 1
Bit 0 = TRIP
16 Bit Unsigned Integer – Physical Output Select State
Reserved (msb leftmost bit)
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed (lsb rightmost bit)
41175 FORCED LOGICAL IN
Bit 15 = FLI 17
Bit 14 = FLI 18
Bit 13 = FLI 19
Bit 12 = FLI 20
Bit 11 = FLI 21
Bit 10 = FLI 22
Bit 9 = FLI 23
Bit 8 = FLI 24
Bit 7 = FLI 25
Bit 6 = FLI 26
Bit 5 = FLI 27
Bit 4 = FLI 28
Bit 3 = FLI 29
Bit 2 = FLI 30
Bit 1 = FLI 31
Bit 0 = FLI 32
Unsigned Integer 16 Bits – FLI Select Status
0 = Normal, 1 = Forced (msb leftmost bit)
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced (lsb rightmost bit)
41176 FORCED LOGICAL IN
Bit 15 = FLI 1
Bit 14 = FLI 2
Bit 13 = FLI 3
Bit 12 = FLI 4
Bit 11 = FLI 5
Bit 10 = FLI 6
Unsigned Integer 16 Bits – FLI Select Status
0 = Normal, 1 = Forced (msb leftmost bit)
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
