TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
118
Register
Address
Item Description (Multiplier if any)
unreported) record of data.
41666 Parameter Fla
Unsi
ned Inte
er 16 Bit
41667 Fault Type Element Unsigned 16 Bit
00 = 87T – % Differential Alarm
01 = 87H – High Set Inst. Differential Alarm
02 = 51P-1 – Winding 1 Phase Time Overcurrent
03 = 51P-2 – Winding 2 Phase Time Overcurrent
04 = 50P-1 – 1
st
Winding 1 Phase Inst. Overcurrent
05 = 50N-1 – 1
st
Winding 1 Neutral Inst. Overcurrent
06 = 150P-1 – 2
nd
Winding 1 Phase Inst. Overcurrent
07 = 150N-1 – 2
nd
Winding 1 Neutral Inst. Overcurrent
08 = 46-1 – Neg. Sequence 1 Inst. Time Overcurrent
09 = 51P-2 – Winding 2 Phase Time Overcurrent
10 = 51G-2 – Winding 2 Ground Time Overcurrent
11 = 50P-2 – 1
st
Winding 2 Phase Inst. Overcurrent
12 = 50G-2 – 1
st
Winding 2 Ground Inst. Overcurrent
13 = 150P-2 – 2
nd
Winding 2 Phase Inst. Overcurrent
14 = 150G-2 – 2
nd
Winding 2 Ground Inst. Overcurrent
15 = 46-2 – Neg. Sequence 2 Inst. Time Overcurrent
16 = ECI-1 – Event Capture Initiate 1
17 = ECI-2 – Event Capture Initiate 2
18 = Through Fault
19 = Harmonic Restraint
41668 Setting At Fault Event Unsigned 16 Bit
01 = Primary Settings
02 = Alternate 1 Settings
03 = Alternate 2 Settings
41669 Fault Record Number
Unsigned 16 Bit
(1 – 999, only last 32 kept)
41670 Year 2 digit 00 -99 Unsigned 16 Bit Year of Fault
41671 Month 1 - 12 Unsigned 16 Bit Month of Fault
41672 Day 1 - 31 Unsigned 16 Bit Day of Fault
41673 Hour 00 - 23 Unsigned 16 Bit Hour of Fault
41674 Minute 00 - 59 Unsigned 16 Bit Minute of Fault
41675 Second 00 - 59 Unsigned 16 Bit Second of Fault
41676 Hundredths of Seconds 0 - 99 Unsigned 16 Bit Hundredth Second of Fault Time
41677 Clear Time Unsigned 16 Bit (X 1000) seconds
41678 Winding1 Tap Unsigned 16 Bit (X 500)
41679 Winding2 Tap Unsigned 16 Bit (X 800)
41680 I operate Phase A Unsigned 16 Bit (X 800)
41681 I operate Phase B Unsigned 16 Bit (X 800)
41682 I operate Phase C Unsigned 16 Bit (X 800)
41683 I restraint Phase A-Winding 1 Unsigned 16 Bit (X 800)
41684 I restraint Phase B-Winding 1 Unsigned 16 Bit (X 800)
41685 I restraint Phase C-Winding 1 Unsigned 16 Bit (X 800)
41686 I restraint Phase A-Winding 2 Unsigned 16 Bit (X 800)
41687 I restraint Phase B-Winding 2 Unsigned 16 Bit (X 800)
41688 I restraint Phase C-Winding 2 Unsigned 16 Bit (X 800)
41689 2nd Harmonic Phase A-Winding 1 Unsigned 16 Bit (X 2)
41690 5th Harmonic Phase A-Winding 1 Unsigned 16 Bit (X 2)
41691 All Harmonic Phase A-Winding 1 Unsigned 16 Bit (X 2)
41692 2nd Harmonic Phase B-Winding 1 Unsigned 16 Bit (X 2)
41693 5th Harmonic Phase B-Winding 1 Unsigned 16 Bit (X 2)
41694 All Harmonic Phase B-Winding 1 Unsigned 16 Bit (X 2)
41695 2nd Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
To Next Page
