TPU2000/2000R Modbus/Modbus Plus Automation Guide
123
Register
Address
Item Description (Multiplier if any)
17 = ECI-2 – Event Capture Initiate 2
18 = Through Fault
19 = Harmonic Restraint
41796 Setting At Fault Event Unsigned 16 Bit
01 = Primary Settings
02 = Alternate 1 Settings
03 = Alternate 2 Settings
41797 Fault Record Number Unsigned 16 Bit
(1 – 999, only last 32 kept)
41798 Year 2 digit 00 -99 Unsigned 16 Bit Year of Fault
41799 Month 1 - 12 Unsigned 16 Bit Month of Fault
41800 Day 1 - 31 Unsigned 16 Bit Day of Fault
41801 Hour 00 - 23 Unsigned 16 Bit Hour of Fault
41802 Minute 00 - 59 Unsigned 16 Bit Minute of Fault
41803 Second 00 - 59 Unsigned 16 Bit Second of Fault
41804 Hundredths of Seconds 0 - 99 Unsigned 16 Bit Hundredth Second of Fault Time
41805 Clear Time Unsigned 16 Bit (X 1000) seconds
41806 Relay Time (MSW) Most Significant Word Unsigned 16 Bit (X 1000)
41807 Relay Time (LSW) Least Significant Word Unsigned 16 Bit (X 1000)
41808 I Phase A-Winding 1 Unsigned 16 Bit (X 800)
41809 I PhaseB-Winding 1 Unsigned 16 Bit (X 800)
41810 I Phase C-Winding 1 Unsigned 16 Bit (X 800)
41811 I Neutral-Winding 1 Unsigned 16 Bit (X 800)
41812 I Phase A-Winding 2 Unsigned 16 Bit (X 800)
41813 I Phase B-Winding 2 Unsigned 16 Bit (X 800)
41814 I Phase C-Winding 2 Unsigned 16 Bit (X 800)
41815 I Neutral –Winding 2 Unsigned 16 Bit (X 800)
41816 Spare Unsigned 16 Bit
41817 I Phase A-Winding 1 (Ang) Unsigned 16 Bit
41818 I Phase B-Winding 1 (Ang) Unsigned 16 Bit
41819 I Phase C-Winding 1 (Ang) Unsigned 16 Bit
41820 I Neutral-Winding 1 (Ang) Unsigned 16 Bit
41821 I Phase A-Winding 2 (Ang) Unsigned 16 Bit
41822 I Phase B-Winding 2 (Ang) Unsigned 16 Bit
41823 I Phase C-Winding 2 (Ang) Unsigned 16 Bit
41824 I Neutral-Winding 2 (Ang) Unsigned 16 Bit
41825 I 0-1 – Zero Sequence Current
Winding 1
Unsigned 16 Bit (X 800)
41826 I 1-1 – Positive Sequence
Current Winding 1
Unsigned 16 Bit (X 800)
41827 I 2-1 – Negative Sequence
Current Winding 1
Unsigned 16 Bit (X 800)
41828 I 0-2 – Zero Sequence Current
Winding 2
Unsigned 16 Bit (X 800)
41829 I 1-2 – Positive Sequence
Current Winding 2
Unsigned 16 Bit (X 800)
41830 I 2-2 – Negative Sequence
Current Winding 2
Unsigned 16 Bit (X 800)
41831 I 0-1 (Ang) – Zero Sequence
Angle Winding 1
Unsigned 16 Bit
41832 I 1-1 (Ang) – Positive
Sequence Angle Winding 1
Unsigned 16 Bit
41833 I 2-1 (Ang) – Negative
Sequence Angle Winding 1
Unsigned 16 Bit
