TPU2000/2000R Modbus/Modbus Plus Automation Guide
169
Register
Address
3 Winding
Item Description
Bit 13 = 79V
Bit 14 = 81S-1
Bit 15 = 81R –1 (msb)
Recloser Lockout
Frequency Shed (First Stage)
Frequency Restore (First Stage)
42825 Quarter Cycle Miscellaneous Data Word 1
Reserved
Unsigned Integer 16 Bits
Reserved
42826 Quarter Cycle Miscellaneous Data Word 2
Bit 0 = Master Trip(lsb)
Bit 1 = 52 a
Bit 2 = BFA
Bit 3 = Reserved
Bit 4 = Reserved
Bit 5 = Reserved
Bit 6 = Reserved
Bit 7 = Reserved
Bit 8 = Reserved
Bit 9 = Reserved
Bit10 = Reserved
Bit 11 = Reserved
Bit 12 = Reserved
Bit 13 = Reserved
Bit 14 = Reserved
Bit 15 = Reserved (msb)
Unsigned Integer 16 Bits
Master Trip Status
Breaker Status (1 = Open, 0 = Closed)
Breaker Fail Alarm
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
OSCILLOGRAPHIC DATA POINTS
42827 CHANNEL 1 POINT 1 Signed Integer 16 Bits
42828 CHANNEL 2 POINT 1 Signed Integer 16 Bits
42829 CHANNEL 3 POINT 1 Signed Integer 16 Bits
42830 CHANNEL 4 POINT 1 Signed Integer 16 Bits
42831 CHANNEL 5 POINT 1 Signed Integer 16 Bits
42832 CHANNEL 6 POINT 1 Signed Integer 16 Bits
42833 CHANNEL 7 POINT 1 Signed Integer 16 Bits
42834 CHANNEL 1 POINT 2 Signed Integer 16 Bits
42835 CHANNEL 2 POINT 2 Signed Integer 16 Bits
42836 CHANNEL 3 POINT 2 Signed Integer 16 Bits
42837 CHANNEL 4 POINT 2 Signed Integer 16 Bits
42838 CHANNEL 5 POINT 2 Signed Integer 16 Bits
42839 CHANNEL 6 POINT 2 Signed Integer 16 Bits
42840 CHANNEL 7 POINT 2 Signed Integer 16 Bits
42841 CHANNEL 1 POINT 3 Signed Integer 16 Bits
42842 CHANNEL 2 POINT 3 Signed Integer 16 Bits
42843 CHANNEL 3 POINT 3 Signed Integer 16 Bits
42844 CHANNEL 4 POINT 3 Signed Integer 16 Bits
42845 CHANNEL 5 POINT 3 Signed Integer 16 Bits
42846 CHANNEL 6 POINT 3 Signed Integer 16 Bits
42847 CHANNEL 7 POINT 3 Signed Integer 16 Bits
42848 CHANNEL 1 POINT 4 Signed Integer 16 Bits
42849 CHANNEL 2 POINT 4 Signed Integer 16 Bits
42850 CHANNEL 3 POINT 4 Signed Integer 16 Bits
42851 CHANNEL 4 POINT 4 Signed Integer 16 Bits
42852 CHANNEL 5 POINT 4 Signed Integer 16 Bits
42853 CHANNEL 6 POINT 4 Signed Integer 16 Bits
42854 CHANNEL 7 POINT 4 Signed Integer 16 Bits
42855 CHANNEL 1 POINT 5 Signed Integer 16 Bits
42856 CHANNEL 2 POINT 5 Signed Integer 16 Bits
42857 CHANNEL 3 POINT 5 Signed Integer 16 Bits
