ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
203
Register
Address
Item Description
61282 Access Password ASCII – 2 Characters Leftmost Digits
61283 Access Password ASCII – 2 Characters Rightmost Digits
61284 SPARE_2
61285 87T Curve Type Unsigned Integer 16 Bits
61286 87T Minimum I Operate Unsigned 16 Bits
0.2 <=Range <=1.0 (X10)
61287 87T Percent Restraint 15<=Range<=60
61288 87T Restraint Mode Unsigned Integer 16 Bits
Refer to Mode Selection Table
61289 87T 2
nd
Harmonic Restraint Unsigned Integer 16 Bits
7.5<=Range<=25 (X10)
61290 87T 5
th
Harmonic Restraint Unsigned Integer 16 Bits
15<=Range<=40 (X10)
61291 87T All Harmonic Restraint Unsigned Integer 16 Bits
15<=Range<=40 (X10)
61292 87H Tap X Byte Unsigned Integer 16 Bits
6 <=Range<=20 (X10)
61293 87T-1 Amp Unsigned Integer 16 Bits
2<=Range<=9 (X10)
0.4<=Range<=1.8 (X50)
61294 51P-1 Curve Select (TYPE I) Unsigned 16 Bits
Range 0-12 (See Text Above)
61295 51P-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61296 51P-1 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 (X20) Time Dial
0<=Range<=10 (X20) Time Delay
61297 50P-1 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
61298 50P-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61299 50P-1 Time Dial/Time Delay Unsigned 16 Bits
Dial *10
Delay * 100
61300 150P-1 Curve Select Unsigned Integer 16 bits
See Table Above
61301 150P-1 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
61302 150P-1 Time Dial Unsigned 16 Bits
0<=Range<=9.99 * 100
61303 46-1 Curve Select Byte Unsigned Integer 16 bits
See Table Above
61304 46-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61305 46-1 Time Dial/Time Delay Unsigned 16 Bits
1<=Range<=12 * 10
0.2<=Range<= 0.4 *50
61306 51N-1 Curve Select (TYPE II) Unsigned 16 Bits
Range 0-12 (See Text Above)
61307 51N-1 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
61308 51N-1 Time Dial Unsigned 16 Bits
