TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
266
Bit 8: DSP ROM FAILURE
Bit 7: Spare
Bit 6: Spare
Bit 5: Spare
Bit 4: Spare
Bit 3: CPU EEPROM FAILURE
Bit 2: CPU NVRAM FAILURE
Bit 1: CPU EPROM FAILURE
Bit 0: CPU RAM FAILURE
Offset 6: Unsigned Word Relay Configuration
Bit 15-4: Spare
Bit 3: 0=kWhr/kVarhr, 1=MWhr/MVarhr
Bit 2: 0= Wye PT, 1=Delta PT
Bit 1,0: Meter Winding Mode (0=Winding 1,
1=Winding2, 2=Winding3)
Offset 8: 20 Char String(NULL Term) Catalog Number
Offset 28: Unsigned Short 100 CPU Software Version Number
Offset 30: Unsigned Short 10 Analog/DSP Software Version Number
Offset 32: Unsigned Short 10 Front Panel Controller Software Version Number
Offset 34: Unsigned Short 10 Auxillary Communication Software Version Number
Offset 36: Unsigned Long 1 Serial Number
Offset 40: 18 Char String (NULL Term) Unit Name
BLK 1:
DIFFERENTIAL CURRENT/ANGULAR/HARMONIC VALUES BLOCK
Block Offset
Data Size Scale Description
Offset 0: Unsigned Word 800 Operate Current-A
Offset 2: Unsigned Word 800 Operate Current-B
Offset 4: Unsigned Word 800 Operate Current-C
Offset 6: Unsigned Word 800 Restraint Current-A Winding 1
Offset 8: Unsigned Word 800 Restraint Current-B Winding 1
Offset 10: Unsigned Word 800 Restraint Current-C Winding 1
Offset 12: Unsigned Word 800 Restraint Current-A Winding 2
Offset 14: Unsigned Word 800 Restraint Current-B Winding 2
Offset 16: Unsigned Word 800 Restraint Current-C Winding 2
Offset 18: Unsigned Word 800 Restraint Current-A Winding 3
Offset 20: Unsigned Word 800 Restraint Current-B Winding 3
Offset 22: Unsigned Word 800 Restraint Current-C Winding 3
Offset 24: Unsigned Word 1 Restraint Angle-A Winding 1
Offset 26: Unsigned Word 1 Restraint Angle-B Winding 1
Offset 28: Unsigned Word 1 Restraint Angle-C Winding 1
Offset 30: Unsigned Word 1 Restraint Angle-A Winding 2
Offset 32: Unsigned Word 1 Restraint Angle-B Winding 2
Offset 34: Unsigned Word 1 Restraint Angle-C Winding 2
Offset 36: Unsigned Word 1 Restraint Angle-A Winding 3
Offset 38: Unsigned Word 1 Restraint Angle-B Winding 3
Offset 40: Unsigned Word 1 Restraint Angle-C Winding 3
Offset 42: Unsigned Word 1 Restraint Angle-B Winding 3
Offset 44: Unsigned Byte 2 % Second Harmonic-A Winding 1
Offset 45: Unsigned Byte 2 % Second Harmonic-B Winding 1
Offset 46: Unsigned Byte 2 % Second Harmonic-C Winding 1
Offset 47: Unsigned Byte 2 % Fifth Harmonic-A Winding 1
Offset 48: Unsigned Byte 2 % Fifth Harmonic-B Winding 1
Offset 49: Unsigned Byte 2 % Fifth Harmonic-C Winding 1
Offset 50: Unsigned Byte 2 % All Harmonic-A Winding 1
Offset 51: Unsigned Byte 2 % All Harmonic-B Winding 1
Offset 52: Unsigned Byte 2 % All Harmonic-C Winding 1
Offset 53: Unsigned Byte 2 % Second Harmonic-A Winding 2
Offset 54: Unsigned Byte 2 % Second Harmonic-B Winding 2
