ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
272
Offset 119: Unsigned Byte Spare
BLK 7:
COUNTERS BLOCK
Block Offset
Data Size Scale Description
Offset 0: Unsigned Short 1 Unreported Differential Fault Record Counter
Offset 2: Unsigned Short 1 Unreported Through Fault Record Counter
Offset 4: Unsigned Short 1 Unreported Harmonic Restraint Record Counter
Offset 6: Unsigned Short 1 Unreported Operation Record Counter
Offset 8: Unsigned Short 1 Through Fault Counter
Offset 10: Unsigned Long 1 Through Fault Summation kAmps-A Counter
Offset 14: Unsigned Long 1 Through Fault Summation kAmps-B Counter
Offset 18: Unsigned Long 1 Through Fault Summation kAmps-C Counter
Offset 22: Unsigned Long 1 Through Fault Summation Cycles Counter
Offset 26: Unsigned Short 1 Overcurrent Trip Counter
Offset 28: Unsigned Short 1 Differential Trip Counter
BLK 8:
PHYSICAL and LOGICAL INPUT/OUTPUT BLOCK
Block Offset
Data Size Description
Offset 0: Unsigned Long Logical Output 0-31
Bit 31: DIFF Bit 15: 51G-2
Bit 30: ALARM Bit 14: 50N-1
Bit 29: 87T Bit 13: 150N-1
Bit 28: 87H Bit 12: 50G-2
Bit 27: 2HROA Bit 11: 150G-2
Bit 26: 5HROA Bit 10: 46-1
Bit 25: AHROA Bit 9: 46-2
Bit 24: TCFA Bit 8: 87T-D
Bit 23: TFA Bit 7: 87H-D
Bit 22: 51P-1 Bit 6: 51P-1D
Bit 21: 51P-2 Bit 5: 51P-2D
Bit 20: 50P-1 Bit 4: 51N-1D
Bit 19: 150P-1 Bit 3: 51G-2D
Bit 18: 50P-2 Bit 2: 50P-1D
Bit 17: 150P-2 Bit 1: 50P-2D
Bit 16: 51N-1 Bit 0: 50N-1D
Offset 4: Unsigned Long Logical Output 32-63
Bit 31: 50G-2D Bit 15: DTC
Bit 30: 150P-1D Bit 14: OCTC
Bit 29: 150P-2D Bit 13: PDA
Bit 28: 150N-1D Bit 12: NDA
Bit 27: 150G-2D Bit 11: PRIM
Bit 26: 46-1D Bit 10: ALT1
Bit 25: 46-2D Bit 9: ALT2
Bit 24: PATA Bit 8: STCA
Bit 23: PBTA Bit 7: 87T*
Bit 22: PCTA Bit 6: 87H*
Bit 21: PUA Bit 5: 2HROA*
Bit 20: 63 Bit 4: 5HROA*
Bit 19: THRUFA Bit 3: AHROA*
Bit 18: TFCA Bit 2: 51P-1*
Bit 17: TFKA Bit 1: 51P-2*
Bit 16: TFSCA Bit 0: 50P-1*
Offset 8: Unsigned Long Logical Output 64-95
Bit 31: 150P-1* Bit 15: ULO5
Bit 30: 50P-2* Bit 14: ULO6
Bit 29: 150P-2* Bit 13: ULO7
Bit 28: 51N-1* Bit 12: ULO8
