TPU2000/2000R Modbus/Modbus Plus Automation Guide
275
5/3 Aux Port Parameter 4 byte (0-255)
6/1 Aux Port Parameter 5 byte (0-255)
6/2 Aux Port Parameter 6 byte (0-255)
6/3 Aux Port Parameter 7 byte (0-255)
7/1 Aux Port Parameter 8 byte (0-255)
7/2 Aux Port Parameter 9 byte (0-255)
7/3 Aux Port Parameter 10 byte (0-255)
8/1 Aux Port Parameter Mode byte
8/2 Spare
8/3 Spare
9/1 Spare
9/2 Checksum high byte
9/3 Checksum low byte
4 Transmit Buffer "N" Commands ( 3 4 n )
N
Definition
0 Reserved for repeat 3 4 n
1 Programmable Input Select and Index Tables
2 Programmable Input Negated AND Table
3 Programmable Input AND/OR Table
4 Programmable Input User Defined Input Names
5 Programmable Output Select Table
6 Programmable Output AND/OR Table
7 Programmable Output User Defined Output Strings
8 Primary Relay Settings
9 Alternate 1 Relay Settings
10 Alternate 2 Relay Settings
11 Configuration Settings
12 Counter Settings
13 Alarm Settings
14 Real Time Clock
15 Output Delays
4.1 Transmit Programmable Input Select and Index ( 3 4 1 )
Bit = 0, Physical Input is selected.
Bit = 1, Physical Input is not selected.
Low byte consists of bits 0 through 7.
High byte consists of bits 8 through 15.
Index byte is the offset into the TPU's logical input structure.
Offset
Definitions
00 87T Restrained Differential Trip
01 87H High Set Inst Differential Trip
02 51P-1 Wdg1 Phase Time OC Trip
03 51P-2 Wdg2 Phase Time OC Trip
04 51N-1 Wdg1 Neutral Time OC Trip
05 51G-2 Wdg2 Ground Time OC Trip
06 50P-1 1st Wdg1 Phase Inst OC Trip
07 50P-2 1st Wdg2 Phase Inst OC Trip
08 50N-1 1st Wdg1 Neutral Inst OC Trip
09 50G-2 1st Wdg2 Ground Inst OC Trip
10 150P-1 2nd Wdg1 Phase Inst OC Trip
11 150P-2 2nd Wdg2 Phase Inst OC Trip
12 150N-1 2nd Wdg1 Neutral Inst OC Trip
13 150G-2 2nd Wdg2 Ground Inst OC Trip
14 46-1 Wdg1 Neg Seq Time OC Trip
15 46-2 Wdg2 Neg Seq Time OC Trip
