TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
334
8/1 Spare
8/2 Checksum (high byte)
8/3 Checksum low byte)
13.6 Send Overcurrent Curve Data Set ( 3 13 6 )
Data Byte
Definition
1/1 User Programmable Curve number: 1=User 1; 2=User 2; 3=User 3
1/2 Block number
1/3 Programmable curve number + Block number
Msg Byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0xd6
1/3 Total Number of Messages = 29
2/1 Programmable curve number
User Programmable Curve number: 1=User 1; 2=User 2; 3=User 3
2/2 Block number
2/3 Segment 0: Endrange (high byte)
3/1 Segment 0: Endrange (low byte)
3/2 Segment 0: Alpha (high byte)
3/3 Segment 0: Alpha |
4/1 Segment 0: Alpha |
4/2 Segment 0: Alpha (low byte)
4/3 Segment 0: Beta (high byte)
5/1 Segment 0: Beta |
5/2 Segment 0: Beta |
5/3 Segment 0: Beta (low byte)
6/1-9/1 Segment 1 (same as segment 0)
9/2-12/2 Segment 2 (same as segment 0)
12/3-15/3 Segment 3 (same as segment 0)
16/1-19/1 Segment 4 (same as segment 0)
19/2-22/2 Segment 5 (same as segment 0)
22/3-25/3 Segment 6 (same as segment 0)
26/1-29/1 Segment 7 (same as segment 0)
29/2 Checksum (high byte)
29/3 Checksum (low byte)
13.7 Send Overcurrent Curve Pointer Table ( 3 13 7 )
Data Byte
Definition
1/1 Programmable curve number
User Programmable Curve number: 1=User 1; 2=User 2; 3=User 3
1/2 Programmable curve number
1/3 Programmable curve number
Msg Byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0xd7
1/3 Total Number of Messages = 25
2/1 Programmable curve number
User Programmable Curve number: 1=User 1; 2=User 2; 3=User 3
2/2 Pointer offset 0
2/3 Pointer offset 1
3/1 Pointer offset 2
3/2 Pointer offset 3
3/3 Pointer offset 4
4/1 Pointer offset 5
4/2 Pointer offset 6
