TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
338
24/3 Data Point 32: (same as Data Point 0)
25/1 Data Point 32: (same as Data Point 0)
25/2 Data Point 33: (same as Data Point 0)
25/3 Data Point 33: (same as Data Point 0)
26/1 Data Point 34: (same as Data Point 0)
26/2 Data Point 34: (same as Data Point 0)
26/3 Data Point 35: (same as Data Point 0)
27/1 Data Point 35: (same as Data Point 0)
27/2 Data Point 36: (same as Data Point 0)
27/3 Data Point 36: (same as Data Point 0)
28/1 Data Point 37: (same as Data Point 0)
28/2 Data Point 37: (same as Data Point 0)
28/3 Data Point 38: (same as Data Point 0)
29/1 Data Point 38: (same as Data Point 0)
29/2 Data Point 39: (same as Data Point 0)
29/3 Data Point 39: (same as Data Point 0)
30/1 Data Point 40: (same as Data Point 0)
30/2 Data Point 40: (same as Data Point 0)
30/3 Data Point 41: (same as Data Point 0)
31/1 Data Point 41: (same as Data Point 0)
31/2 Data Point 42: (same as Data Point 0)
31/3 Data Point 42: (same as Data Point 0)
32/1 Data Point 43: (same as Data Point 0)
32/2 Data Point 43: (same as Data Point 0)
32/3 Data Point 44: (same as Data Point 0)
33/1 Data Point 44: (same as Data Point 0)
33/2 Data Point 45: (same as Data Point 0)
33/3 Data Point 45: (same as Data Point 0)
34/1 Data Point 46: (same as Data Point 0)
34/2 Data Point 46: (same as Data Point 0)
34/3 Data Point 47: (same as Data Point 0)
35/1 Data Point 47: (same as Data Point 0)
35/2 Data Point 48: (same as Data Point 0)
35/3 Data Point 48: (same as Data Point 0)
36/1 Data Point 49: (same as Data Point 0)
36/2 Data Point 49: (same as Data Point 0)
36/3 Data Point 50: (same as Data Point 0)
37/1 Data Point 50: (same as Data Point 0)
37/2 Data Point 51: (same as Data Point 0)
37/3 Data Point 51: (same as Data Point 0)
38/1 Data Point 52: (same as Data Point 0)
38/2 Data Point 52: (same as Data Point 0)
38/3 Spare
39/1 Spare
39/2 Checksum (high byte)
39/3 Checksum (low byte)
13.10 Receive Next Differential Curve Data Set ( 3 13 10 )
Same format as ( 3 13 9 ).
13.11 Send Differential Curve Parameters ( 3 13 11 )
For the unit to receive the Differential curve data, the following sequence of commands must be issued.
3 13 11 (Differential Curve Parameters)
3 13 12 (Operate Threshold Data Points) Block 0
3 13 12 (Operate Threshold Data Points) Block 1
3 13 12 (Operate Threshold Data Points) Block 2
