TPU2000/2000R Modbus/Modbus Plus Automation Guide
341
27/1 Data Point 36: (same as Data Point 0)
27/2 Data Point 37: (same as Data Point 0)
27/3 Data Point 37: (same as Data Point 0)
28/1 Data Point 38: (same as Data Point 0)
28/2 Data Point 38: (same as Data Point 0)
28/3 Data Point 39: (same as Data Point 0)
29/1 Data Point 39: (same as Data Point 0)
29/2 Data Point 40: (same as Data Point 0)
29/3 Data Point 40: (same as Data Point 0)
30/1 Data Point 41: (same as Data Point 0)
30/2 Data Point 41: (same as Data Point 0)
30/3 Data Point 42: (same as Data Point 0)
31/1 Data Point 42: (same as Data Point 0)
31/2 Data Point 43: (same as Data Point 0)
31/3 Data Point 43: (same as Data Point 0)
32/1 Data Point 44: (same as Data Point 0)
32/2 Data Point 44: (same as Data Point 0)
32/3 Data Point 45: (same as Data Point 0)
33/1 Data Point 45: (same as Data Point 0)
33/2 Data Point 46: (same as Data Point 0)
33/3 Data Point 46: (same as Data Point 0)
34/1 Data Point 47: (same as Data Point 0)
34/2 Data Point 47: (same as Data Point 0)
34/3 Data Point 48: (same as Data Point 0)
35/1 Data Point 48: (same as Data Point 0)
35/2 Data Point 49: (same as Data Point 0)
35/3 Data Point 49: (same as Data Point 0)
36/1 Data Point 50: (same as Data Point 0)
36/2 Data Point 50: (same as Data Point 0)
36/3 Data Point 51: (same as Data Point 0)
37/1 Data Point 51: (same as Data Point 0)
37/2 Data Point 52: (same as Data Point 0)
37/3 Data Point 52: (same as Data Point 0)
38/1 Spare
38/2 Checksum (high byte)
38/3 Checksum (low byte)
14 Waveform Capture Commands ( 3 14 n )
N
Definition
0 Define waveform capture settings
1 Show waveform capture settings
2 Start waveform data accumulation
3 Stop waveform data accumulation
4 Report waveform record data headers
5 Fetch first block of a record (Part A)
6 Fetch next block of a record (Part A)
7 Retransmit last block of a record (Part A)
8 Fetch first block of a record (Part B)
9 Fetch next block of a record (Part B)
10 Retransmit last block of a record (Part B)
11 Fetch Acquisition Status
14.0 Define Waveform Capture Settings ( 3 14 0 )
Note the trigger sources are OR'ed together.
Example: if 3/1 is Hex 07 ;trigger on 87T or 87H or 51P-1 pickup. The capture is 8 cycles of waveform with 32 samples per
cycle. We then have 8 inputs each of 8 cycles captured. The inputs are Ia-1,Ib-1,Ic-1,In-1, Ia-2 Ib-2 Ic-2 and Ig-2 . The data
is sent from the TPU in quarter cycle records, that is 32/4 samples per analog variable.
