ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
344
bit 0, 1: 00 = 8 rec of 8 qtr cycle record
01 = 4 rec of 16 qtr cycle record
10 = 2 rec of 32 qtr cycle record
11 = 1 rec of 64 qtr cycle record
bit 6: Single Shot Mode (0=Off, 1=On)
bit 7: Append Record Mode (0=Off, 1=On)
9/1 Spare
9/2 Checksum (high byte)
9/3 Checksum (low byte)
14.2 Arm Waveform Data Accumulation ( 3 14 2 )
14.3 Disarm Waveform Data Accumulation ( 3 14 3 )
14.4 Report Waveform Record Data Headers ( 3 14 4 )
Msg Byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0xe4
1/3 Total Number of Messages = 38
2/1 - 6/3 Unit ID Name (15 characters)
7/1 Record 0: Trigger position
7/2 Record 0: Year
7/3 Record 0: Month
8/1 Record 0: Date
8/2 Record 0: Hour
8/3 Record 0: Minute
9/1 Record 0: Second
9/2 Record 0: Hundredth of second
9/3 Record 0: Spare
10/1 Record 0: Spare
10/2 Record 0: Mode/Record Size
bit 0, 1: 00 = 8 rec of 8 qtr cycle record
01 = 4 rec of 16 qtr cycle record
10 = 2 rec of 32 qtr cycle record
11 = 1 rec of 64 qtr cycle record
bit 6: Single Shot Mode (0=Off, 1=On)
bit 7: Append Record Mode (0=Off, 1=On)
10/3 Record 0: Spare
11/1 - 14/3 Record 1 (same as record 0)
15/1 - 18/3 Record 2 ( " )
19/1 - 22/3 Record 3 ( " )
23/1 - 26/3 Record 4 ( " )
27/1 - 30/3 Record 5 ( " )
31/1 - 34/3 Record 6 ( " )
35/1 - 38/3 Record 7 ( " )
14.5 Fetch First Block of a Record-Part A ( 3 14 5 )
Data Byte
Definition
1/1 Record number (0 to 7)
1/2 Record number (0 to 7)-Duplicate
1/3 Record number (0 to 7)-Triplicate
Msg Byte
Definition
1/1 Relay status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0xe5
1/3 Total Number of Messages = 45
2/1 Record number
