TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
346
Bit 4: 5th Harmonic Restraint
Bit 5: All Harmonic Restraint
6/3 Pickup status (High high byte)
7/1 Pickup status (High low byte)
7/2 Pickup status (Low high byte)
Bit 0: 46-1
Bit 1: 51P-2
Bit 2: 51G-2
Bit 3: 50P-2
Bit 4: 50G-2
Bit 5: 150P-2
Bit 6: 150G-2
Bit 7: 46-2
7/3 Pickup status (Low low byte)
Bit 0: 87T
Bit 1: 87H
Bit 2: 51P-1
Bit 3: 51N-1
Bit 4: 50P-1
Bit 5: 50N-1
Bit 6: 150P-1
Bit 7: 150N-1
8/1 Fault status (High high byte)
8/2 Fault status (High low byte)
8/3 Fault status (Low high byte)
Bit 0: 46-1
Bit 1: 51P-2
Bit 2: 51G-2
Bit 3: 50P-2
Bit 4: 50G-2
Bit 5: 150P-2
Bit 6: 150G-2
Bit 7: 46-2
9/1 Fault status (Low low byte)
Bit 0: 87T
Bit 1: 87H
Bit 2: 51P-1
Bit 3: 51N-1
Bit 4: 50P-1
Bit 5: 50N-1
Bit 6: 150P-1
Bit 7: 150N-1
9/2 Spare
9/3 Spare
14.9 Fetch Next Block of a Record-Part B ( 3 14 9 )
Same message format as ( 3 14 8 )
14.10 Retransmit Last Block of a Record-Part B ( 3 14 10 )
Same message format as ( 3 14 8 )
14.11 Fetch Acquisition Status ( 3 14 11 )
Msg Byte
Definition
1/1 Relay status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0xeb
1/3 Total Number of Messages = 2
