ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
50
Register
Address
Item Description
(Momentary)
00535: 50P-1 STATUS 1
st
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Status)
00536: 50P-1 MOMENTARY 1
st
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00537: 150P-1 STATUS 2
nd
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Status)
00538: 150P-1 MOMENTARY 2
nd
Winding 1 Phase Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00539: 50P-2 STATUS 1
st
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized (Status)
00540: 50P-2 MOMENTARY 1
st
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00541: 150P-2 STATUS 2
nd
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized (Status)
00542: 150P-2 MOMENTARY 2
nd
Winding 2 Phase Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00543: 51N-1 STATUS Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(Status)
00544: 51N-1 MOMENTARY Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(Momentary)
00545: 51N-2 STATUS Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(Status)
00546: 51N-2 MOMENTARY Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(Momentary)
00547: 50N-1 STATUS 1
st
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Status)
00548: 50N-1 MOMENTARY 1
st
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00549: 150N-1 STATUS 2
nd
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Status)
00550: 150N-1 MOMENTARY 2
nd
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00551: 50N-2 STATUS 1
st
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Status)
00552: 50N-2 MOMENTARY 1
st
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00553: 150N-2 STATUS 2
nd
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Status)
00554: 150N-2 MOMENTARY 2
nd
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm
Energized (Momentary)
00555: 46-1 STATUS Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized (Status)
00556: 46-1 MOMENTARY Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized (Momentary)
00557: 46-2 STATUS Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized (Status)
00558: 46-2 MOMENTARY Winding 1 Negative Sequence Time Overcurrent Trip Alarm
Energized (Momentary)
00559: 87T-D STATUS Percentage Differential Disabled Alarm Energized (Status)
00560: 87T-D MOMENTARY Percentage Differential Disabled Alarm Energized
(Momentary)
00561: 87H-D STATUS High Set Instantaneous Function Disabled Alarm Energized
(Status)
00562: 87H-D MOMENTARY Hi
g
h Set Instantaneous Function Disabled Alarm Ener
g
ized
