TPU2000/2000R Modbus/Modbus Plus Automation Guide
65
Note Register
Address
Item Description
10003: 51P-1 Winding 1 Phase Time Overcurrent Control Enabled
10004: 51P-2 Winding 2 Phase Time Overcurrent Control Enabled
10005: 51N-1 Winding 1 Neutral Time Overcurrent Control Enabled
10006: 51N-2 Winding 2 Neutral Time Overcurrent Control Enabled
10007: 50P-1 1
st
Winding 1 Phase Time Instantaneous Control Enabled
10008: 50P-2 1
st
Winding 2 Phase Time Instantaneous Control Enabled
10009: 50N-1 1
st
Winding 1 Neutral Time Instantaneous Control Enabled
10010: 50N-2 1
st
Winding 2 Neutral Time Instantaneous Control Enabled
10011: 150P-1 2
nd
Winding 1 Phase Time Instantaneous Control Enabled
10012: 150P-2 2
nd
Winding 2 Phase Time Instantaneous Control Enabled
10013: 150N-1 2
nd
Winding 1 Neutral Time Instantaneous Control Enabled
10014: 150N-2 2
nd
Winding 2 Neutral Time Instantaneous Control Enabled
10015: 46-1 Winding 1 Negative Sequence Control Enabled
10016: 46-2 Winding 2 Negative Sequence Control Enabled
10017: ALT1 Enable Alternate 1 Settings
10018: ALT2 Enable Alternate 2 Settings
10019: ECI1 Initiate Event Capture 1
10020: ECI2 Initiate Event Capture 2
10021: WCI Waveform Capture Initiate
10022: TRIP Differential Trip Output Initiated
10023: SPR Sudden Pressure Relay Input Intiated
10024: TCM Trip Coil Monitor
10025: ULI1 User Logical Input 1 Element Energized
10026: ULI2 User Logical Input 2 Element Energized
10027: ULI3 User Logical Input 3 Element Energized
10028: ULI4 User Logical Input 4 Element Energized
10029: ULI5 User Logical Input 5 Element Energized
10030: ULI6 User Logical Input 6 Element Energized
10031: ULI7 User Logical Input 7 Element Energized
10032: ULI8 User Logical Input 8 Element Energized
10033: ULI9 User Logical Input 9 Element Energized
10034: CRI Reclose and Overcurrent Counters Cleared
3 10035: Reserved Reserved
3 10036: Reserved Reserved
3 10037: Reserved Reserved
3 10038: Reserved Reserved
3 10040: Reserved Reserved
3 10041: Reserved Reserved
3 10042: Reserved Reserved
3 10043: Reserved Reserved
3 10044: Reserved Reserved
3 10045: Reserved Reserved
3 10046: Reserved Reserved
3 10047: Reserved Reserved
3 10048: Reserved Reserved
3 10049: Reserved Reserved
3 10050: Reserved Reserved
3 10051: Reserved Reserved
3 10052: Reserved Reserved
3 10053: Reserved Reserved
3 10054: Reserved Reserved
3 10055: Reserved Reserved
3 10056: Reserved Reserved
3 10057: Reserved Reserved
