TPU2000/2000R Modbus/Modbus Plus Automation Guide
67
Notes Register
Address
Item Description
10513 87T Status 2 or 3 Winding 3- Phase % Differential Current Control (Status)
10514 87T Momentary 2 or 3 Winding 3- Phase % Differential Current Control (Momentary)
10515 87H Status 2 or 3 Winding 3 Phase % High Set Instantaneous Differential Current
Control (Status)
10516 87H Momentary 2 or 3 Winding 3 Phase % High Set Instantaneous Differential Current
Control (Momentary)
10517 51P-1 Status Winding 1 Phase Time Overcurrent Control Enabled (Status)
10518 51P-1 Momentary Winding 1 Phase Time Overcurrent Control Enabled (Momentary)
10519 51P-2 Status Winding 2 Phase Time Overcurrent Control Enabled (Status)
10520 51P-2 Momentary Winding 2 Phase Time Overcurrent Control Enabled (Momentary)
10521 51N-1 Status Winding 1 Neutral Time Overcurrent Control Enabled (Status)
10522 51N-1
Momentary
Winding 1 Neutral Time Overcurrent Control Enabled (Momentary)
10523 51N-2 Status Winding 2 Neutral Time Overcurrent Control Enabled (Status)
10524 51N-2
Momentary
Winding 2 Neutral Time Overcurrent Control Enabled (Momentary)
10525 50P-1 Status 1
st
Winding 1 Phase Time Instantaneous Control Enabled (Status)
10526 50P-1 Momentary 1
st
Winding 1 Phase Time Instantaneous Control Enabled
(Momentary)
10527 50P-2 Status 1
st
Winding 2 Phase Time Instantaneous Control Enabled (Status)
10528 50P-2 Momentary 1
st
Winding 2 Phase Time Instantaneous Control Enabled
(Momentary)
10529 50N-1 Status 1
st
Winding 1 Neutral Time Instantaneous Control Enabled (Status)
10530 50N-1
Momentary
1
st
Winding 1 Neutral Time Instantaneous Control Enabled
(Momentary)
10531 50N-2 Status 1
st
Winding 2 Neutral Time Instantaneous Control Enabled (Status)
10532 50N-2
Momentary
1
st
Winding 2 Neutral Time Instantaneous Control Enabled
(Momentary)
10533 150P-1 Status 2
nd
Winding 1 Phase Time Instantaneous Control Enabled (Status)
10534 150P-1
Momentary
2
nd
Winding 1 Phase Time Instantaneous Control Enabled
(Momentary)
10535 150P-2 Status 2
nd
Winding 2 Phase Time Instantaneous Control Enabled (Status)
10536 150P-2
Momentary
2
nd
Winding 2 Phase Time Instantaneous Control Enabled
(Momentary)
10537 150N-1 Status 2
nd
Winding 1 Neutral Time Instantaneous Control Enabled (Status)
10538 150N-1
Momentary
2
nd
Winding 1 Neutral Time Instantaneous Control Enabled
(Momentary)
10539 150N-2 Status 2
nd
Winding 2 Neutral Time Instantaneous Control Enabled (Status)
10540 150N-2
Momentary
2
nd
Winding 2 Neutral Time Instantaneous Control Enabled
(Momentary)
10541 46-1 Status Winding 1 Negative Sequence Control Enabled (Status)
10542 46-1 Momentary Winding 1 Negative Sequence Control Enabled (Momentary)
10543 46-2 Status Winding 2 Negative Sequence Control Enabled (Status)
10544 46-2 Momentary Winding 2 Negative Sequence Control Enabled (Momentary)
10545 ALT1 Status Enable Alternate 1 Settings (Status)
10546 ALT1 Momentary Enable Alternate 1 Settings (Momentary)
10547 ALT2 Status Enable Alternate 2 Settings (Status)
10548 ALT2 Momentary Enable Alternate 2 Settings (Momentary)
10549 ECI1 Status Initiate Event Capture 1 (Status)
10550 ECI1 Momentary Initiate Event Capture 1 (Momentary)
10551 ECI2 Status Initiate Event Capture 2 (Status)
10552 ECI2 Momentary Initiate Event Capture 2 (Momentary)
10553 WCI Status Waveform Capture Initiate (Status)
10554 WCI Momentary Waveform Capture Initiate (Momentary)
